Запчасти Komatsu WA900-3LC B-A ДЕМПФЕР КОМПОНЕНТЫ ДВИГАТЕЛЯ

|$0

427-12-11013

DAMPER ASSEMBLY

SN: A50001--UP

1шт.

1

427-12-11118

COVER

SN: A50001--UP

1шт.

2

427-12-11147

SHAFT

SN: A50001--UP

1шт.

|$3

427-12-11215

BODY ASSEMBLY, INNER

SN: A50001--UP

1шт.

3

427-12-11156

BODY, INNER

SN: A50001--UP

1шт.

4

427-12-11223

SPACER

SN: A50001--UP

1шт.

5

427-12-11164

BODY, OUTER

SN: A50001--UP

1шт.

6

427-12-11980

RUBBER

SN: A50001--UP

6шт.

7

01010-61650

BOLT

SN: A50001--UP

12шт.

8

01643-31645

WASHER

SN: A50001--UP

12шт.

9

06040-06219

BEARING

SN: A50001--UP

2шт.

10

427-12-11262

SPACER

SN: A50001--UP

1шт.

11

427-12-11343

SEAL, OIL

SN: A50001--UP

1шт.

12

427-12-11353

SEAL, OIL

SN: A50001--UP

1шт.

13

04071-00170

RING, SNAP

SN: A50001--UP

1шт.

14

01010-61235

BOLT

SN: A50001--UP

16шт.

15

01643-31232

WASHER

SN: A50001--UP

16шт.

16

07030-01030

BREATHER

SN: A50001--UP

1шт.

17

427-12-11176

FLANGE

SN: A50001--UP

1шт.

18

427-12-11185

FLANGE

SN: A50001--UP

1шт.

19

01253-31610

BOLT

SN: A50001--UP

6шт.

20

01643-31645

WASHER

SN: A50001--UP

6шт.

21

427-12-11240

O-RING

SN: A50001--UP

2шт.

22

04064-09530

RING, SNAP

SN: A50001--UP

1шт.

23

07043-00211

PLUG

SN: A50001--UP

1шт.

24

427-12-11370

COVER

SN: A50001--UP

1шт.

25

427-12-11380

GASKET

SN: A50001--UP

1шт.

26

01252-30825

BOLT

SN: A50001--UP

8шт.

27

01643-50825

WASHER

SN: A50001--UP

8шт.

28

07030-00252

BREATHER

SN: A50001--UP

1шт.

29

427-12-11871

GREASE

SN: A50001--UP

1шт.
