Запчасти Komatsu WA900-1 КЛАПАН УПРАВЛЕНИЯ ТРАНСМИССИЕЙ (/) ТРАНСМИССИЯ

|$0

427-15-00013

TRANSMISSION ASS'Y

SN: 10001-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.2501 TO 2534.

-1шт.

|$2

427-15-00201

CONTROL VALVE A.

SN: 10001-UP

1шт.

|$$4

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.2531 TO 2534.

-1шт.

|$4

427-15-00300

VALVE ASS'Y

SN: 10001-UP

1шт.

|$$6

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.2531 TO 2533.

-1шт.

1

195-15-35110

BODY,VALVE

SN: 10001-UP

1шт.

2

195-15-35320

VALVE,REVERSE

SN: 10001-UP

1шт.

3

195-15-35330

VALVE,FORWARD, 1ST, 2ND

SN: 10001-UP

3шт.

4

195-15-35340

VALVE,3RD

SN: 10001-UP

1шт.

5

195-15-35370

STOPPER

SN: 10001-UP

5шт.

6

07000-72018

O-RING (K4)

SN: 10001-UP

5шт.

7

568-15-15330

SPRING, (L= 78.0)

SN: 10001-UP

5шт.

8

07000-73028

O-RING (K4)

SN: 10001-UP

5шт.

9

07000-72018

O-RING (K4)

SN: 10001-UP

1шт.

10

195-15-35380

PLATE

SN: 10001-UP

1шт.

11

01010-51030

BOLT

SN: 10001-UP

6шт.

12

01643-51032

WASHER

SN: 10001-UP

6шт.

13

195-15-35910

GASKET (K4)

SN: 10001-UP

1шт.

14

01010-51090

BOLT

SN: 10001-UP

2шт.

15

01643-31032

WASHER

SN: 10001-UP

2шт.
