Запчасти Komatsu WA800-2 КЛАПАН УПРАВЛЕНИЯ ТРАНСМИССИЕЙ (/) ТРАНСМИССИЯ

|$$1

SERIAL NO. IN ( ) INDICATES TORQUE CONVERTER SERIAL NO.

-1шт.

|$1

427-15-01001

TORQFLOW ASS'Y

SN: (1045)-(1100)

1шт.

|$2

0

TORQFLOW ASS'Y

SN: 10001-(1044)

1шт.

|$$4

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.2301 TO 2524.

-1шт.

|$$5

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|$5

427-15-00013

TRANSMISSION ASS'Y

SN: (1144)-UP

1шт.

|$6

0

TRANSMISSION ASS'Y

SN: (1101)-(1143)

1шт.

|$7

427-15-00011

TRANSMISSION ASS'Y

SN: 10001-(1100)

1шт.

|$$9

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.2501 TO 2524.

-1шт.

|$9

427-15-00201

CONTROL VALVE A.

SN: (1101)-UP

1шт.

|$10

427-15-00200

CONTROL VALVE A.

SN: 10001-(1100)

1шт.

|$$12

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.2521 TO 2524.

-1шт.

|$12

427-15-00300

VALVE ASS'Y

SN: 10001-UP

1шт.

|$$14

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.2521 TO 2523.

-1шт.

1

195-15-35110

BODY,VALVE

SN: 10001-UP

1шт.

2

195-15-35320

VALVE,REVERSE

SN: 10001-UP

1шт.

3

195-15-35330

VALVE,FORWARD, 1ST, 2ND

SN: 10001-UP

3шт.

4

195-15-35340

VALVE,3RD

SN: 10001-UP

1шт.

5

195-15-35370

STOPPER

SN: 10001-UP

5шт.

6

07000-72018

O-RING (K4)

SN: 10001-UP

5шт.

7

568-15-15330

SPRING, (L= 78.0)

SN: 10001-UP

5шт.

8

07000-73028

O-RING (K4)

SN: 10001-UP

5шт.

9

07000-72018

O-RING (K4)

SN: 10001-UP

1шт.

10

195-15-35380

PLATE

SN: 10001-UP

1шт.

11

01010-81030

BOLT

SN: 10001-UP

6шт.

12

01643-51032

WASHER

SN: 10001-UP

6шт.

13

195-15-35910

GASKET (K4)

SN: 10001-UP

1шт.

14

01010-81090

BOLT

SN: 10001-UP

2шт.

15

01643-31032

WASHER

SN: 10001-UP

2шт.
