Запчасти Komatsu WA800-1 КОРПУС ТРАНСМИССИИ ТРАНСМИССИЯ

|$$1

SERIAL NO. IN ( ) INDICATES TORQUE CONVERTER SERIAL NO.

-1шт.

|$1

427-15-01001

TORQFLOW ASS'Y

SN: (1045)-(1100)

1шт.

|$2

0

TORQFLOW ASS'Y

SN: 10001-(1044)

1шт.

|$$4

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.2301 TO 2524.

-1шт.

|$$5

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|$5

427-15-00013

TRANSMISSION ASS'Y

SN: (1144)-UP

1шт.

|$6

0

TRANSMISSION ASS'Y

SN: (1101)-(1143)

1шт.

|$7

427-15-00011

TRANSMISSION ASS'Y

SN: 10001-(1100)

1шт.

|$$9

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.2501 TO 2524.

-1шт.

1

427-15-11110

CASE

SN: 10001-UP

1шт.

2

07042-70211

PLUG

SN: (1308)-UP

1шт.

2

07042-00211

PLUG

SN: 10001-(1307)

1шт.

3

07048-02216

PLUG

SN: (1292)-UP

2шт.

3

04530-02438

BOLT,EYE

SN: 10001-(1291)

2шт.

4

198-15-21310

SLEEVE

SN: 10001-UP

4шт.

5

07000-73030

O-RING (K3)

SN: 10001-UP

4шт.

6

07000-73050

O-RING (K3)

SN: 10001-UP

4шт.

7

07000-72065

O-RING (K3)

SN: 10001-UP

2шт.

8

07000-73025

O-RING (K3)

SN: 10001-UP

6шт.

9

07000-73035

O-RING (K3)

SN: 10001-UP

3шт.

10

07000-02085

O-RING (K3)

SN: 10001-UP

1шт.

11

07000-05190

O-RING (K3)

SN: 10001-UP

2шт.

12

281-09-11110

O-RING (K3)

SN: (1387)-UP

1шт.

12

0

O-RING (K3)

SN: 10001-(1386)

1шт.

13

09608-05080

PLATE, NAME,(LIMITED SUPPLY)

SN: 10001-UP

1шт.

14

04418-13060

SCREW

SN: 10001-UP

4шт.

15

01010-61645

BOLT

SN: 10001-UP

4шт.

16

01643-31645

WASHER

SN: 10001-UP

4шт.

17

01010-61645

BOLT

SN: 10001-UP

13шт.

18

01643-31645

WASHER

SN: 10001-UP

13шт.
