|$$1
SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.
-1шт.
|$1
428-13-05010
SERVICE KIT,TORQUE CONVERTER
SN: 10001-UP
1шт.
1
428-13-05020
SERVICE KIT,TORQUE CONVERTER CASE
SN: 10001-UP
1шт.
1
711-33-13340
O-RING,CASE
SN: 10001-UP
1шт.
1
07000-72105
O-RING,CASE
SN: 10001-UP
4шт.
1
07000-72085
O-RING,CASE
SN: 10001-UP
1шт.
1
07000-73028
O-RING,CASE
SN: 10001-UP
1шт.
1
07005-01212
GASKET,OIL PIPING
SN: 10001-UP
16шт.
1
07000-75230
O-RING,PTO CASE COVER
SN: 10001-UP
1шт.
1
07012-10110
SEAL,OIL, RETAINER
SN: 10001-UP
1шт.
1
07000-75145
O-RING,RETAINER
SN: 10001-UP
1шт.
1
07000-75075
O-RING,COUPLING
SN: 10001-UP
1шт.
2
562-13-05040
SERVICE KIT,TORQUE CONVERTER VALVE
SN: 10001-UP
1шт.
2
07000-63048
O-RING,VALVE
SN: 10001-UP
1шт.
2
07000-72014
O-RING,VALVE
SN: 10001-UP
2шт.
2
07000-73048
O-RING,VALVE
SN: 10001-UP
1шт.
2
07000-72014
O-RING,VALVE
SN: 10001-UP
1шт.
2
07000-73045
O-RING,VALVE COVER
SN: 10001-UP
2шт.
|$18
428-15-05012
SERVICE KIT,TRANSMISSION
SN: (1054)-UP
1шт.
|$19
428-15-05011
SERVICE KIT,TRANSMISSION
SN: (1037)-(1053)
1шт.
|$20
428-15-05010
SERVICE KIT,TRANSMISSION
SN: 10001-(1036)
1шт.
3
428-15-05020
SERVICE KIT,TRANSMISSION CASE
SN: 10001-UP
1шт.
3
07000-72021
O-RING,TRANSMISSION CASE
SN: 10001-UP
6шт.
3
170-09-17130
O-RING,TRANSMISSION CASE
SN: 10001-UP
6шт.
3
07000-73030
O-RING,TRANSMISSION CASE
SN: 10001-UP
10шт.
3
07000-72018
O-RING,TRANSMISSION CASE
SN: 10001-UP
6шт.
3
07000-72021
O-RING,TRANSMISSION CASE
SN: 10001-UP
1шт.
3
07002-03034
O-RING,PLUG
SN: 10001-UP
2шт.
3
07002-03634
O-RING,VALVE BODY
SN: 10001-UP
1шт.
3
07000-73025
O-RING,VALVE BODY
SN: 10001-UP
1шт.
3
07000-02145
O-RING,TRANSFER CASE
SN: 10001-UP
1шт.
3
07000-73040
O-RING,TRANSFER CASE
SN: 10001-UP
1шт.
3
07000-02115
O-RING,COVER
SN: 10001-UP
3шт.
3
07000-02100
O-RING,FLANGE
SN: 10001-UP
4шт.
3
07000-73028
O-RING,VALVE BODY
SN: 10001-UP
1шт.
3
426-15-19610
O-RING,TRANSFER CASE
SN: 10001-UP
1шт.
3
07000-73048
O-RING,FILTER TUBE
SN: 10001-UP
1шт.
3
07000-02070
O-RING,TUBE
SN: 10001-UP
2шт.
3
287-15-19220
RING,SEAL, HOUSING, REVERSE
SN: 10001-UP
1шт.
3
155-15-12811
RING,SEAL, PISTON, REVERSE
SN: 10001-UP
1шт.
3
198-15-29230
RING,SEAL, FORWARD HOUSING
SN: 10001-UP
1шт.
3
195-15-39220
RING,SEAL, HOUSING, FORWARD
SN: 10001-UP
1шт.
3
287-15-19220
RING,SEAL, HOUSING, 4TH
SN: 10001-UP
1шт.
3
155-15-12811
RING,SEAL, 4TH HOUSING
SN: 10001-UP
1шт.
3
155-15-12811
RING,SEAL, 1ST HOUSING
SN: 10001-UP
1шт.
3
582-15-19240
RING,SEAL, HOUSING, 1ST
SN: 10001-UP
1шт.
3
103-15-12811
RING,SEAL
SN: 10001-UP
1шт.
3
562-15-19220
RING,SEAL
SN: 10001-UP
1шт.
3
582-15-19240
RING,SEAL, HOUSING, 3RD
SN: 10001-UP
1шт.
3
195-15-39220
RING,SEAL, HOUSING, 3RD
SN: 10001-UP
1шт.
3
07000-05240
O-RING,CAGE
SN: 10001-UP
1шт.
3
07012-10150
SEAL,OIL CAGE
SN: 10001-UP
1шт.
3
07000-05195
O-RING,CAGE
SN: 10001-UP
1шт.
3
428-15-05110
SHIM ASS'Y
SN: 10001-UP
1шт.
3
0
SHIM, 0.15MM
SN: 10001-UP
4шт.
3
0
SHIM, 0.2MM
SN: 10001-UP
6шт.
3
0
SHIM, 0.3MM
SN: 10001-UP
6шт.
3
175-30-16210
O-RING,HOLDER
SN: 10001-UP
1шт.
3
07012-10130
SEAL,OIL CAGE
SN: 10001-UP
1шт.
3
07000-05180
O-RING,CAGE
SN: 10001-UP
1шт.
3
07000-05300
O-RING,CAGE
SN: 10001-UP
1шт.
3
428-15-05120
SHIM ASS'Y
SN: 10001-UP
1шт.
3
0
SHIM, 0.2MM
SN: 10001-UP
2шт.
3
0
SHIM, 0.3MM
SN: 10001-UP
3шт.
3
0
SHIM, 1.0MM
SN: 10001-UP
2шт.
3
07000-05220
O-RING,CAGE
SN: 10001-UP
1шт.
3
07000-72021
O-RING,COVER
SN: 10001-UP
1шт.
3
07000-05280
O-RING,CAGE
SN: 10001-UP
1шт.
3
428-15-05130
SHIM ASS'Y
SN: 10001-UP
1шт.
3
0
SHIM, 0.2MM
SN: 10001-UP
2шт.
3
0
SHIM, 0.2MM
SN: 10001-UP
2шт.
3
0
SHIM, 0.3MM
SN: 10001-UP
3шт.
3
0
SHIM, 0.3MM
SN: 10001-UP
3шт.
3
0
SHIM, 1.0MM
SN: 10001-UP
2шт.
3
0
SHIM, 1.0MM
SN: 10001-UP
2шт.
3
07000-05200
O-RING,CAGE
SN: 10001-UP
1шт.
3
428-15-05140
SHIM ASS'Y
SN: 10001-UP
1шт.
3
0
SHIM, 0.2MM
SN: 10001-UP
2шт.
3
0
SHIM, 0.2MM
SN: 10001-UP
2шт.
3
0
SHIM, 0.3MM
SN: 10001-UP
3шт.
3
0
SHIM, 0.3MM
SN: 10001-UP
3шт.
3
0
SHIM, 1.0MM
SN: 10001-UP
2шт.
3
0
SHIM, 1.0MM
SN: 10001-UP
2шт.
3
07000-02130
O-RING,PLATE
SN: 10001-UP
1шт.
3
426-15-19110
O-RING,CAGE
SN: 10001-UP
1шт.
4
428-15-05033
SERVICE KIT,CONTROL VALVE
SN: (1103)-UP
1шт.
4
0
SERVICE KIT,CONTROL VALVE
SN: (1054)-(1102)
1шт.
4
428-15-05031
SERVICE KIT,CONTROL VALVE
SN: (1037)-(1053)
1шт.
4
428-15-05030
SERVICE KIT,CONTROL VALVE
SN: 10001-(1036)
1шт.
4
07000-72021
O-RING,STOPPER
SN: 10001-UP
1шт.
4
424-15-15931
GASKET,COVER
SN: (1103)-UP
1шт.
4
0
GASKET,COVER
SN: 10001-(1102)
1шт.
4
07000-73035
O-RING,COVER
SN: 10001-UP
2шт.
4
07000-72015
O-RING,COVER
SN: 10001-UP
2шт.
4
07000-73030
O-RING,COVER
SN: 10001-UP
1шт.
4
07000-72021
O-RING,COVER
SN: 10001-UP
1шт.
4
07000-73030
O-RING,PLUG
SN: 10001-UP
1шт.
4
07000-72021
O-RING,PLATE
SN: 10001-UP
1шт.
4
07002-03034
O-RING,PLUG
SN: 10001-UP
1шт.
4
07000-73030
O-RING,COVER
SN: 10001-UP
2шт.
4
428-15-15980
GASKET,VALVE BODY
SN: 10001-UP
1шт.
4
07000-73025
O-RING,TUBE
SN: 10001-UP
2шт.
4
07002-03034
O-RING,PLUG
SN: 10001-UP
1шт.
4
425-15-15961
GASKET,COVER
SN: (1103)-UP
1шт.
4
0
GASKET,COVER
SN: 10001-(1102)
1шт.
4
424-15-15921
GASKET,COVER
SN: (1103)-UP
1шт.
4
0
GASKET,COVER
SN: 10001-(1102)
1шт.
4
07000-72014
O-RING,FILTER
SN: 10001-UP
2шт.
4
424-15-15993
GASKET,VALVE BODY
SN: (1103)-UP
1шт.
4
0
GASKET,VALVE BODY
SN: 10001-(1102)
1шт.
4
07000-73045
O-RING,COVER
SN: 10001-UP
2шт.
4
428-15-15930
GASKET,BODY
SN: 10001-UP
1шт.
4
428-15-15940
GASKET,SEAT
SN: 10001-UP
1шт.
4
07000-73035
O-RING,TUBE
SN: 10001-UP
2шт.
4
424-15-17230
GASKET,BODY
SN: (1037)-UP
1шт.
4
22W-06-15690
GASKET,BODY
SN: 10001-(1036)
1шт.
4
07000-71009
O-RING,SPOOL
SN: 10001-UP
6шт.
4
568-15-17260
O-RING,SOLENOID VALVE
SN: 10001-UP
6шт.
4
07000-31006
O-RING,SOLENOID VALVE
SN: 10001-UP
6шт.
4
424-15-17141
GASKET,COVER
SN: (1054)-UP
1шт.
4
424-15-17140
GASKET,COVER
SN: 10001-(1053)
1шт.
4
424-15-17121
GASKET,BODY
SN: 10001-UP
1шт.
