1
426-06-A1111
BATTERY, WET
SN: A60001-UP-UP
2шт.
2
08000-00000
TERMINAL, POSITIVE (+) BATTERY
SN: A60001-UP-UP
2шт.
N/I
08000-00001
TERMINAL, NEGATIVE (-) BATTERY
SN: A60001-UP-UP
2шт.
3
421-06-11221
HOLDER - BATTERY
SN: A60001-UP-UP
2шт.
4
113-06-31120
BOLT - BATTERY HOLD DOWN
SN: A60001-UP-UP
4шт.
5
01580-11008
NUT
SN: A60001-UP-UP
4шт.
6
01584-01008
NUT
SN: A60001-UP-UP
4шт.
7
421-06-11930
RELAY - BATTERY
SN: A60001-UP-UP
1шт.
|$8
01010-80816
BOLT
SN: A60001-UP-UP
2шт.
|$9
01643-50823
WASHER
SN: A60001-UP-UP
2шт.
|$10
01220-40408
SCREW
SN: A60001-UP-UP
2шт.
|$11
01601-20410
WASHER
SN: A60001-UP-UP
2шт.
8
01435-00825
BOLT - RELAY MOUNTING
SN: A60001-UP-UP
2шт.
9
425-06-11113
BOX, BATTERY - L.H.
SN: A60001-UP-UP
1шт.
N/I
425-50-15530
SHIM
SN: A60001-UP-UP
-2шт.
10
425-06-11123
BOX, BATTERY - R.H.
SN: A60001-UP-UP
1шт.
N/I
425-50-15530
SHIM
SN: A60001-UP-UP
-2шт.
11
421-09-12321
LATCH - BATTERY BOX
SN: A60001-UP-UP
2шт.
12
01220-40410
SCREW - LATCH
SN: A60001-UP-UP
4шт.
13
01220-40408
SCREW - LATCH
SN: A60001-UP-UP
6шт.
14
01641-20405
WASHER
SN: A60001-UP-UP
10шт.
15
426-06-11280
ROD
SN: A60001-UP-UP
2шт.
16
01643-31032
WASHER
SN: A60001-UP-UP
4шт.
17
04050-13020
PIN, COTTER
SN: A60001-UP-UP
8шт.
18
425-54-11170
COVER, L.H.
SN: A60001-UP-UP
1шт.
19
425-54-11180
COVER, R.H.
SN: A60001-UP-UP
1шт.
20
01435-01020
BOLT, FLANGE HEAD - BATTERY BOX
SN: A60001-UP-UP
4шт.
21
415-54-11980
CUSHION
SN: A60001-UP-UP
4шт.
22
425-06-11410
GUARD
SN: A60001-UP-UP
2шт.
23
01435-01016
BOLT - GUARD
SN: A60001-UP-UP
8шт.
24
01010-31665
BOLT - BATTERY BOX
SN: A60001-UP-UP
8шт.
25
01643-31645
WASHER
SN: A60001-UP-UP
8шт.
26
421-54-18520
BOX - TOOL
SN: A60001-UP-UP
1шт.
27
421-54-18530
SEAL
SN: A60001-UP-UP
2шт.
28
421-54-18540
SEAL
SN: A60001-UP-UP
2шт.
