Запчасти Komatsu WA500-1LC FIG. F-A ПЕРЕДНИЙ МОСТ - ДИФФЕРЕНЦ. СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$0

AXLE ASSEMBLY, FRONT(SEE FIG. F4400-01A0)

SN: A60001-UP-UP

1шт.

|$1

425-22-11011

DIFFERENTIAL ASSEMBLY

SN: A60001-UP-UP

1шт.

|$2

425-22-00010

CARRIER AND CAP ASSEMBLY

SN: A60001-UP-UP

1шт.

1

NSS

CARRIER, DIFFERENTIAL

SN: A60001-UP-UP

1шт.

2

NSS

CAP - DIFFERENTIAL BEARING

SN: A60001-UP-UP

2шт.

3

175-21-12180

PIN, DOWEL

SN: A60001-UP-UP

4шт.

4

01011-62420

BOLT - BEARING CAP

SN: A60001-UP-UP

4шт.

5

01643-32460

WASHER

SN: A60001-UP-UP

4шт.

|$8

425-22-00020

PINION AND RING GEAR ASSEMBLY

SN: A60001-UP-UP

1шт.

6

NSS

GEAR - PINION

SN: A60001-UP-UP

1шт.

7

NSS

GEAR - RING

SN: A60001-UP-UP

1шт.

8

425-22-11831

BEARING - ROLLER

SN: A60001-UP-UP

1шт.

9

04064-05520

RING, RETAINING

SN: A60001-UP-UP

1шт.

|$13

425-22-11500

CASE ASSEMBLY

SN: A60001-UP-UP

1шт.

10

NSS

CASE, HALF - PLAIN

SN: A60001-UP-UP

1шт.

11

NSS

CASE, HALF - FLANGED

SN: A60001-UP-UP

1шт.

12

01011-31610

BOLT

SN: A60001-UP-UP

12шт.

13

01643-31645

WASHER

SN: A60001-UP-UP

12шт.

14

175-21-12180

PIN, DOWEL

SN: A60001-UP-UP

4шт.

15

01010-31645

BOLT

SN: A60001-UP-UP

24шт.

16

01643-31645

WASHER

SN: A60001-UP-UP

24шт.

17

425-22-11411

SPIDER

SN: A60001-UP-UP

1шт.

18

425-22-11450

GEAR - PINION

SN: A60001-UP-UP

4шт.

19

425-22-11560

WASHER, THRUST

SN: A60001-UP-UP

4шт.

20

425-22-11430

GEAR - SIDE

SN: A60001-UP-UP

2шт.

21

425-22-11531

WASHER, THRUST

SN: A60001-UP-UP

2шт.

22

562-13-12260

BEARING - ROLLER

SN: A60001-UP-UP

2шт.

23

425-22-11140

NUT - BEARING ADJUSTMENT

SN: A60001-UP-UP

2шт.

24

425-22-11150

LOCK - BEARING CAP

SN: A60001-UP-UP

2шт.

25

01010-30820

BOLT

SN: A60001-UP-UP

4шт.

26

01643-30823

WASHER - M8

SN: A60001-UP-UP

4шт.

27

425-22-11130

CAGE

SN: A60001-UP-UP

1шт.

28

07000-05200

O-RING - CAGE

SN: A60001-UP-UP

1шт.

29

07000-05190

O-RING - CAGE

SN: A60001-UP-UP

1шт.

30

425-22-11811

BEARING ASSEMBLY

SN: A60001-UP-UP

1шт.

31

425-22-11312

COVER - CAGE

SN: A60001-UP-UP

1шт.

32

07012-00100

SEAL, OIL - CAGE COVER

SN: A60001-UP-UP

1шт.

33

425-22-11760

SEAL, CAGE COVER

SN: A60001-UP-UP

1шт.

34

425-22-00030

SHIM KIT

SN: A60001-UP-UP

1шт.

|$39

425-22-11390

SHIM - 0.008 IN. (0.20 MM)

SN: A60001-UP-UP

4шт.

|$40

425-22-11380

SHIM - 0.012 IN. (0.30 MM)

SN: A60001-UP-UP

2шт.

|$41

425-22-11370

SHIM - 0.039 IN. (1.00 MM)

SN: A60001-UP-UP

2шт.

35

01010-31665

BOLT, CAGE COVER

SN: A60001-UP-UP

10шт.

36

01643-31645

WASHER

SN: A60001-UP-UP

10шт.

37

425-22-11230

COUPLING

SN: A60001-UP-UP

1шт.

38

425-22-11240

HOLDER

SN: A60001-UP-UP

1шт.

39

07000-05065

O-RING, COUPLING

SN: A60001-UP-UP

1шт.

40

01051-62440

BOLT - COUPLING

SN: A60001-UP-UP

1шт.

41

195-21-12380

O-RING - DIFFERENTIAL CARRIER

SN: A60001-UP-UP

1шт.

42

04020-01638

PIN, DOWEL

SN: A60001-UP-UP

1шт.

43

01010-62050

BOLT - DIFFERENTIAL CARRIER

SN: A60001-UP-UP

18шт.

44

01643-32060

WASHER

SN: A60001-UP-UP

18шт.

|$52

425-22-05011

KIT, SERVICE - FRONT DIFFERENTIAL

SN: A60001-UP-UP

1шт.

|$53

-1шт.

|$54

F1 - INCLUDED IN FRONT DIFFERENTIAL SERVICE KIT.

-1шт.

|$55

-1шт.
