Запчасти Komatsu WA450-3-H КЛАПАН УПРАВЛЕНИЯ ТРАНСМИССИЕЙ (ГЛАВНЫЙ ФИЛЬТР) ТРАНСМИССИЯ

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|1

714-07-10041

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: 64001-UP

1шт.

|1

714-07-10040

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: 63001-64000

1шт.

|$$4

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-69A0.

-1шт.

|1

714-07-15012

VALVE ASS'Y,TRANSMISSION

SN: 65001-UP

1шт.

|1

714-07-15011

VALVE ASS'Y,TRANSMISSION

SN: 63001-65000

1шт.

|$$7

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-61A0 TO F4350-63A0.

-1шт.

1

419-15-16660

FILTER ASS'Y,PILOT

SN: 63001-UP

1шт.

|1

419-15-16930

ELEMENT

SN: 63001-UP

1шт.

|1

419-15-16940

HEAD

SN: 63001-UP

1шт.

|1

419-15-16950

O-RING

SN: 63001-UP

1шт.

|1

419-15-16960

CASE,FILTER

SN: 63001-UP

1шт.

2

07000-02014

O-RING (K2)

SN: 63001-UP

2шт.

3

01010-81035

BOLT

SN: 63001-UP

2шт.

4

01642-21016

WASHER

SN: 63001-UP

2шт.

5

01602-01030

WASHER,SPRING

SN: 63001-UP

2шт.

6

714-07-15911

GASKET,UPPER VALVE (K2)

SN: (106691)-UP

1шт.

|6

0

GASKET,UPPER VALVE (K2)

SN: 63001-(106690)

1шт.

7

01010-81070

BOLT

SN: 63001-UP

1шт.

8

01010-81045

BOLT

SN: 63001-UP

1шт.
