Запчасти Komatsu WA450-2 FIG NO. A ДВИГАТЕЛЬ И АКСЕССУАРЫ КОМПОНЕНТЫ ДВИГАТЕЛЯ & ЭЛЕКТРИКА

|$0

421-01-A1010

ENGINE AND ACCESSORIES

1шт.

1

421-01-A1114

ENGINE ASSEMBLY

1шт.

2

CLEANER ASSEMBLY, AIR (SEE PG 01-010)

-29шт.

3

CONNECTIONS, AIR CLEANER (SEE PG 01-008)

-29шт.

4

421-01-A1140

FAN, ENGINE BLOWER

1шт.

5

1208 400 H1

SPACER, FAN PILOT

1шт.

6

25 684 R1

BOLT - 3/8-16NC X 5-1/2 IN

6шт.

7

MOTOR ASSEMBLY, CRANKING (SEE PG 01-014)

-29шт.

N/I

01010-81650

BOLT

3шт.

N/I

01643-31645

WASHER

3шт.

8

ALTERNATOR ASSEMBLY (SEE PG 01-020)

-29шт.

N/I

01643-31032

WASHER

1шт.

9

MUFFLER, EXHAUST (SEE PG 01-012)

-29шт.

10

421-01-A1260

BRACKET, FILTER MOUNTING

1шт.

N/I

01010-81230

BOLT

5шт.

N/I

01643-31232

WASHER

5шт.

N/I

01010-81035

BOLT

4шт.

N/I

01643-31032

WASHER

4шт.

N/I

25 553 R1

WASHER, FLAT - 3/8 IN. ID

4шт.

N/I

01580-01008

NUT

4шт.

N/I

24 840 R1

BOLT - 3/8-16NC X 1 IN

4шт.

N/I

25 534 R1

WASHER, FLAT - 3/8 IN. ID

4шт.

11

421-01-A1170

RELAY, STARTER DISABLE

1шт.

12

421-06-A1170

BRACKET, RELAY MOUNTING

1шт.

N/I

01435-00816

BOLT

2шт.

13

206-01-A1140

SENSOR ASSEMBLY, ENGINE OIL LEVEL

1шт.

|$26

206-01-A1160

SENSOR, ENGINE OIL LEVEL

1шт.

|$27

1209 470 H1

CONNECTOR, MALE

1шт.

|$28

1209 477 H1

SEAL, TERMINAL

4шт.

|$29

1209 466 H1

TERMINAL

4шт.

14

206-01-A1150

SWITCH, ENGINE OIL PRESSURE

1шт.

15

444 024

BUSHING, REDUCER

1шт.

16

206-01-A1130

SENSOR, ENGINE COOLANT TEMPERATURE

1шт.

17

GOVERNOR ASSEMBLY, AIR (SEE PG 03-070)

-29шт.

N/I

25 236 R1

BOLT - 5/16-18NC X 3 IN

2шт.

N/I

120 214

WASHER, LOCK - 5/16 IN. ID

2шт.

N/I

25 533 R1

WASHER, FLAT - 5/16 IN. ID

2шт.

18

421-01-A1290

GASKET, GOVERNOR MOUNTING

1шт.

|$43

-1шт.

|$39

F1 - FOR SERVICE PARTS, SEE SECTION E.

-1шт.

|$44

-1шт.

|$45

-1шт.

|$42

F2 - REFERENCE PARTS AND SERVICE NEWS A925001.

-1шт.

|$46

-1шт.
