Запчасти Komatsu WA380-6 ЗАДН. МОСТ (ДИФФЕРЕНЦ.¤ /)(№-) ТРАНСМИССИЯ

|$2

423-23-30011

AXLE ASS'Y,REAR

SN: 65001-UP

1шт.

|$3

423-23-30061

AXLE ASS'Y,REAR (LIMITED SLIP DIFF.)

SN: 65001-UP

1шт.

|$$3

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4500-51B0 TO F4500-57B0.

-1шт.

|$5

423-23-31010

DIFFERENTIAL ASS'Y

SN: 65001-UP

1шт.

|$6

423-23-31050

DIFFERENTIAL ASS'Y,(LIMITED SLIP DIFF.)

SN: 65001-UP

1шт.

|$$6

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4500-53B0 TO F4500-55B1.

-1шт.

1

423-23-31231

COUPLING

SN: 65001-UP

1шт.

2

418-22-21310

PROTECTOR

SN: 65001-UP

1шт.

|$11

423-23-31200

PINION AND GEAR A.

SN: 65001-UP

1шт.

3

0

PINION

SN: 65001-UP

1шт.

4

0

GEAR

SN: 65001-UP

1шт.

5

419-22-11810

BEARING

SN: 65001-UP

1шт.

6

423-23-31150

CAGE

SN: 65001-UP

1шт.

7

419-22-11820

BEARING

SN: 65001-UP

1шт.

8

418-22-21330

SEAL

SN: 65001-UP

1шт.

9

423-23-31240

HOLDER

SN: 65001-UP

1шт.

10

01011-61615

BOLT

SN: 65001-UP

1шт.

11

423-23-31570

SHIM, 0.05MM

SN: 65001-UP

3шт.

11

423-23-31580

SHIM, 0.2MM

SN: 65001-UP

3шт.

11

423-23-31590

SHIM, 0.5MM

SN: 65001-UP

2шт.

12

07000-13042

O-RING

SN: 65001-UP

1шт.

13

07000-15210

O-RING

SN: 65001-UP

1шт.

14

423-22-31260

SHIM, 0.05MM

SN: 65001-UP

2шт.

14

423-22-31270

SHIM, 0.2MM

SN: 65001-UP

2шт.

14

423-22-31280

SHIM, 0.3MM

SN: 65001-UP

2шт.

14

423-22-31290

SHIM, 0.8MM

SN: 65001-UP

1шт.

15

01010-61650

BOLT

SN: 65001-UP

10шт.

16

01643-31645

WASHER

SN: 65001-UP

10шт.
