Запчасти Komatsu WA320-3L FIG. B-A КРЕПЛЕНИЕ ДВИГАТЕЛЯ КОМПОНЕНТЫ ДВИГАТЕЛЯ

1

419-01-21110

BRACKET, TRANSMISSION MOUNT

SN: A30001--UP

2шт.

|$1

01010-31650

BOLT, MOUNT BRACKET

SN: A30001--UP

8шт.

|$2

01643-31645

WASHER

SN: A30001--UP

8шт.

2

425-01-11350

CUSHION, TRANSMISSION MOUNT

SN: A30001--UP

4шт.

3

419-01-11162

WASHER

SN: A30001--UP

4шт.

4

01011-62230

BOLT, MOUNT TRANSMISSION TO FRAME

SN: A30001--UP

2шт.

5

01643-32260

WASHER

SN: A30001--UP

2шт.

6

01580-02218

NUT

SN: A30001--UP

2шт.

7

01016-51680

BOLT, ADJUSTMENT

SN: A30001--UP

4шт.

8

01580-01613

NUT

SN: A30001--UP

4шт.

9

419-01-11210

BRACKET, LH - ENGINE MOUNT

SN: A30001--UP

1шт.

|$11

419-01-11270

SPACER

SN: A30001--UP

1шт.

|$12

01010-81265

BOLT, MOUNT BRACKET

SN: A30001--UP

4шт.

|$13

01643-31232

WASHER

SN: A30001--UP

4шт.

10

419-01-11221

BRACKET, RH - ENGINE MOUNT

SN: A30001--UP

1шт.

|$15

01010-81250

BOLT, MOUNT BRACKET

SN: A30001--UP

4шт.

|$16

01643-31232

WASHER

SN: A30001--UP

4шт.

N/I

418-01-11111

CUSHION, ENGINE MOUNT

SN: A30001--UP

2шт.

11

418-01-11120

CUSHION, TOP

SN: A30001--UP

1шт.

12

418-01-11131

CUSHION, BOTTOM

SN: A30001--UP

1шт.

13

419-01-11162

WASHER

SN: A30001--UP

4шт.

14

01011-62230

BOLT, MOUNT ENGINE TO FRAME

SN: A30001--UP

2шт.

15

01643-32260

WASHER

SN: A30001--UP

2шт.

16

01580-02218

NUT

SN: A30001--UP

2шт.
