Запчасти Komatsu WA320-3L FIG. T-A СТРЕЛА ASSEMBLY РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

419-70-21100

ARM ASSEMBLY, LIFT

SN: A30001--UP

1шт.

|$1

419-877-2200

ARM ASSEMBLY, LIFT

SN: A30001--UP

1шт.

|$2

419-879-2200

ARM ASSEMBLY, LIFT

SN: A30001--UP

1шт.

|$3

419-T32-2160

ARM ASSEMBLY, LIFT

SN: A30001--UP

1шт.

|$4

419-S95-2300

ARM ASSEMBLY, LIFT

SN: A30001--UP

1шт.

|$5

419-850-2010

ARM ASSEMBLY, LIFT (HI-LIFT)

SN: A30001--UP

1шт.

1

NSS

ARM, LIFT

SN: A30001--UP

1шт.

2

419-70-11890

BUSHING

SN: A30001--UP

2шт.

3

424-09-12320

SEAL, DUST

SN: A30001--UP

4шт.

4

419-70-21810

BUSHING

SN: A30001--UP

2шт.

5

419-09-11110

SEAL, DUST

SN: A30001--UP

4шт.

6

419-70-11871

BUSHING

SN: A30001--UP

2шт.

7

419-09-11110

SEAL, DUST

SN: A30001--UP

4шт.

8

07020-00000

FITTING, GREASE

SN: A30001--UP

2шт.

9

419-70-11790

PIN

SN: A30001--UP

2шт.

10

07020-00675

FITTING, GREASE

SN: A30001--UP

2шт.

11

419-70-11460

SHIM, 1.5MM

SN: A30001--UP

2шт.

|$17

419-70-11470

SHIM, 3.0MM

SN: A30001--UP

2шт.

12

01010-81625

BOLT

SN: A30001--UP

2шт.

13

421-70-11280

WASHER

SN: A30001--UP

2шт.

14

419-70-11922

PIN

SN: A30001--UP

2шт.

15

419-70-11420

SHIM, 1.5MM

SN: A30001--UP

2шт.

|$22

419-70-11430

SHIM, 3.0MM

SN: A30001--UP

2шт.

16

419-70-11480

ORING

SN: A30001--UP

4шт.

17

01010-81625

BOLT

SN: A30001--UP

2шт.

18

421-70-11280

WASHER

SN: A30001--UP

2шт.

19

419-70-11971

PIN, MOUNTING LIFT ARM CYLINDER

SN: A30001--UP

2шт.

20

419-70-11981

PIN, MOUNTING LIFT ARM CYLINDER

SN: A30001--UP

2шт.

|$29

OR

-1шт.

|$31

419-S95-2880

PIN, MOUNTING LIFT ARM CYLINDER

SN: A30001--UP

2шт.

21

07020-00000

FITTING, GREASE

SN: A30001--UP

4шт.

22

419-70-11420

SHIM, 1.5MM

SN: A30001--UP

4шт.

23

419-09-11110

SEAL, DUST

SN: A30001--UP

4шт.

24

419-70-11440

SHIM, 1.5MM

SN: A30001--UP

2шт.

|$36

419-70-11450

SHIM, 3.0MM

SN: A30001--UP

2шт.

25

419-70-11340

PLATE

SN: A30001--UP

2шт.

26

01010-81630

BOLT

SN: A30001--UP

2шт.

27

01643-31645

WASHER

SN: A30001--UP

2шт.

28

01010-81625

BOLT

SN: A30001--UP

2шт.

29

421-70-11280

WASHER

SN: A30001--UP

2шт.

|$42

-1шт.

|$43

SERVICE PARTS:

-1шт.

|$44

-1шт.

30

419-70-11410

ORING

SN: A30001--UP

4шт.

31

419-70-11490

BOLT

SN: A30001--UP

4шт.

32

01641-20608

WASHER

SN: A30001--UP

8шт.

33

426-09-11130

NUT

SN: A30001--UP

4шт.

|$49

-1шт.

|$50

F1 USED ON MACHINES EQUIPPED WITH STANDARD EQUIPMENT.

-1шт.

|$51

-1шт.

|$52

-1шт.

|$53

F2 USED ON MACHINES EQUIPPED WITH FRONT END ATTACHMENT.

-1шт.

|$54

-1шт.

|$55

-1шт.

|$56

F3 USED ON MACHINES EQUIPPED WITH MULTI-COUPLER.

-1шт.

|$57

-1шт.

|$58

-1шт.

|$59

F4 USED ON MACHINES EQUIPPED WITH M.D.C. MONITOR.

-1шт.

|$60

-1шт.

|$61

-1шт.

|$62

F5 USED ON MACHINES EQUIPPED WITH AUTO GREASE SYSTEM.

-1шт.

|$63

-1шт.

|$64

-1шт.

|$65

F6 USED ON MACHINES EQUIPPED WITH HI-LIFT LIFT ARM.

-1шт.

|$66

-1шт.
