Запчасти Komatsu WA320-3L FIG. J-A ПЕРЕДН. РАМА ОСНОВНАЯ РАМА И ЕЕ ЧАСТИ

1

419-46-21400

FRAME, FRONT

SN: A30001--UP

1шт.

|$2

OR

-1шт.

|$4

419-877-2310

FRAME, FRONT (WITH MONO LEVER)

SN: A30001--UP

1шт.

|$6

OR

-1шт.

|$8

419-S99-2530

FRAME, FRONT (WITH E.C.S.S.)

SN: A30001--UP

1шт.

|$10

OR

-1шт.

|$12

419-S95-2620

FRAME, FR0NT (WITH CENTRAL GREASE SYSTEM)

SN: A30001--UP

1шт.

2

07020-00675

FITTING, GREASE

SN: A30001--UP

2шт.

3

419-46-11360

BEARING

SN: A30001--UP

1шт.

4

419-46-11350

RETAINER

SN: A30001--UP

1шт.

5

421-46-11371

SHIM, 0.1MM

SN: A30001--UP

8шт.

|$17

421-46-11381

SHIM, 0.5MM

SN: A30001--UP

4шт.

6

01010-81230

BOLT

SN: A30001--UP

10шт.

7

01643-31232

WASHER

SN: A30001--UP

10шт.

8

419-09-11110

SEAL, DUST

SN: A30001--UP

2шт.

9

419-46-11330

SHAFT

SN: A30001--UP

1шт.

10

419-46-11340

BUSHING

SN: A30001--UP

1шт.

11

01010-81640

BOLT

SN: A30001--UP

1шт.

12

421-70-11280

WASHER

SN: A30001--UP

1шт.

13

419-46-11281

BEARING

SN: A30001--UP

1шт.

14

419-46-11200

RETAINER

SN: A30001--UP

1шт.

15

419-46-11250

SHIM, 0.1MM

SN: A30001--UP

8шт.

|$28

419-46-11260

SHIM, 0.5MM

SN: A30001--UP

2шт.

|$29

419-46-11270

SHIM, 1.0MM

SN: A30001--UP

4шт.

16

01010-81235

BOLT

SN: A30001--UP

6шт.

17

01643-31232

WASHER

SN: A30001--UP

6шт.

18

419-46-11230

SEAL, DUST

SN: A30001--UP

2шт.

19

419-46-11170

SPACER

SN: A30001--UP

1шт.

20

419-46-11180

SPACER

SN: A30001--UP

1шт.

21

419-46-23210

SHAFT

SN: A30001--UP

1шт.

22

419-46-23221

COVER

SN: A30001--UP

1шт.

23

419-46-11211

SHIM, 0.1MM

SN: A30001--UP

8шт.

|$38

419-46-11221

SHIM, 0.5MM

SN: A30001--UP

6шт.

24

01010-81245

BOLT

SN: A30001--UP

6шт.

25

01643-31232

WASHER

SN: A30001--UP

6шт.

26

01010-61695

BOLT

SN: A30001--UP

3шт.

27

01643-31645

WASHER

SN: A30001--UP

3шт.

28

07020-00675

FITTING, GREASE

SN: A30001--UP

2шт.

29

419-09-11120

SEAL, DUST

SN: A30001--UP

4шт.

30

419-46-12240

PIN, MOUNTING STEERING CYLINDER

SN: A30001--UP

2шт.

|$47

OR

-1шт.

|$49

419-S95-2380

PIN, MOUNTING STEERING CYLINDER

SN: A30001--UP

2шт.

31

01010-81220

BOLT

SN: A30001--UP

2шт.

32

175-54-34170

WASHER

SN: A30001--UP

2шт.

33

419-46-12270

BUSHING

SN: A30001--UP

2шт.

34

419-09-11120

SEAL, DUST

SN: A30001--UP

4шт.

35

419-46-12290

SHIM, 0.5MM

SN: A30001--UP

6шт.

|$55

419-46-12280

SHIM, 1.0MM

SN: A30001--UP

12шт.

36

419-46-12260

PIN, MOUNTING STEERING CYLINDER

SN: A30001--UP

2шт.

37

01010-81220

BOLT

SN: A30001--UP

2шт.

38

175-54-34170

WASHER

SN: A30001--UP

2шт.

39

419-46-24120

COVER, FRONT

SN: A30001--UP

1шт.

|$61

OR

-1шт.

39

419-877-2220

COVER, FRONT (WITH FRONT ATTACHMENT)

SN: A30001--UP

1шт.

40

01435-01225

BOLT

SN: A30001--UP

4шт.

41

01011-32445

BOLT, MOUNTING FRONT AXLE

SN: A30001--UP

8шт.

42

01643-32460

WASHER

SN: A30001--UP

16шт.

43

01580-02419

NUT

SN: A30001--UP

8шт.

|$68

-1шт.

|$69

F1 MODIFIED FRAME FOR MACHINES EQUIPPED WITH MONO LEVER ATTACHMENT.MODIFIED FRAME FOR MACHINES EQUIPPED WITH ELECTRONIC CONTROLLED SUSPENSION SYSTEM.MODIFIED FRAME FOR MACHINES EQUIPPED WITH CENTRAL GREASE SYSTEM.ON MACHINES EQUIPPED WITH

-1шт.

|$70

-1шт.

|$71

-1шт.

|$72

F2 MODIFIED FRAME FOR MACHINES EQUIPPED WITH ELECTRONIC CONTROLLED SUSPENSION SYSTEM.MODIFIED FRAME FOR MACHINES EQUIPPED WITH CENTRAL GREASE SYSTEM.ON MACHINES EQUIPPED WITH FRONT HYDRAULIC ATTACHMENT.

-1шт.

|$73

-1шт.

|$74

-1шт.

|$75

F3 MODIFIED FRAME FOR MACHINES EQUIPPED WITH CENTRAL GREASE SYSTEM.ON MACHINES EQUIPPED WITH FRONT HYDRAULIC ATTACHMENT.

-1шт.

|$76

-1шт.

|$77

-1шт.

|$78

F4 ON MACHINES EQUIPPED WITH FRONT HYDRAULIC ATTACHMENT.

-1шт.

|$79

-1шт.
