Запчасти Komatsu WA320-3 ЗАДН. МОСТ(КОЖУХ МОСТА) F[ТРАНСМИССИЯ]

|$0

419-23-20012

AXLE ASS'Y, REAR THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIG.F4500-01A0 TO 4500-04A0

Field_1: 15001-

1шт.

1

419-23-23410

HOUSING.L.H

Field_1: 15001-

1шт.

2

419-23-23420

HOUSING.R.H

Field_1: 15001-

1шт.

3

0

PLATE.NAME.(LIMITED SUPPLY)

Field_1: 15001-

1шт.

4

04418-13060

SCREW

Field_1: 15001-

4шт.

5

07030-01030

BREATHER

Field_1: 15001-

1шт.

6

04020-01228

PIN

Field_1: 15001-

4шт.

7

01011-61675

BOLT

Field_1: 15001-

32шт.

8

01643-31645

WASHER

Field_1: 15001-

32шт.

9

417-22-23250

PLUG

Field_1: 15001-

1шт.

10

07002-13034

O-RING

Field_1: 15001-

1шт.

11

419-22-13140

PLUG

Field_1: 15001-

2шт.

12

07002-13034

O-RING

Field_1: 15001-

2шт.

13

01252-30816

BOLT

Field_1: 15001-

4шт.

14

154-61-16570

WASHER

Field_1: 15001-

4шт.
