Запчасти Komatsu WA320-3 КЛАПАН УПРАВЛЕНИЯ ТРАНСМИССИЕЙ(/)(СОЛЕНОИДНЫЙ КЛАПАН) F[ТРАНСМИССИЯ]

|$0

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|$1

714-16-20001

TRANSMISSION ASS'Y THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-68A0

Field_1: 15001-

1шт.

|$2

714-16-25030

CONTROL VALVE ASS'Y,T/M ASS'Y THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-61A0 TO F4350-63A0A

Field_1: 15001-

1шт.

|$3

714-11-16200

VALVE ASS'Y,LOWER ASS THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-62A0 TO F4350-63A0A

Field_1: 15001-

1шт.

|$4

714-11-16900

VALVE ASS'Y,SOLENOID

Field_1: 15001-

1шт.

1

714-11-16800

BODY ASS'Y,SOLENOID

Field_1: 15001-

1шт.

2

714-11-16830

SOLENOID VALVE

Field_1: 15001-

2шт.

3

714-11-16840

SOLENOID VALVE

Field_1: 15001-

2шт.

4

714-11-16811

BRACKET

Field_1: 15001-

1шт.

5

01010-80816

BOLT

Field_1: 15001-

2шт.

6

01643-30823

WASHER

Field_1: 15001-

2шт.

7

08034-00414

BAND

Field_1: 15001-

2шт.

8

01010-81085

BOLT

Field_1: 15001-

1шт.

9

01011-81015

BOLT

Field_1: 15001-

1шт.

10

01011-81015

BOLT

Field_1: 15001-

4шт.

11

01010-81085

BOLT

Field_1: 15001-

2шт.

12

01010-81085

BOLT

Field_1: 15001-

1шт.

13

01643-31032

WASHER

Field_1: 15001-

10шт.

14

195-30-34260

WASHER

Field_1: 15001-

1шт.

15

419-06-12840

PLATE

Field_1: 15001-

1шт.

16

07043-70108

PLUG

Field_1: 15001-

1шт.

17

419-15-16811

GASKET,UPPER

Field_1: 15001-

1шт.

18

01010-80860

BOLT

Field_1: 15001-

1шт.

19

01010-80875

BOLT

Field_1: 15001-

1шт.

20

419-15-16660

FILTER ASS'Y

Field_1: 15001-

1шт.

|$25

419-15-16930

ELEMENT

Field_1: 15001-

1шт.

|$26

419-15-16940

HEAD

Field_1: 15001-

1шт.

|$27

419-15-16950

O-RING

Field_1: 15001-

1шт.

|$28

419-15-16960

CASE,FILTER

Field_1: 15001-

1шт.

21

07000-02014

O-RING

Field_1: 15001-

2шт.

22

01010-81035

BOLT

Field_1: 15001-

2шт.

23

01602-01030

WASHER

Field_1: 15001-

2шт.

24

01642-21016

WASHER

Field_1: 15001-

2шт.
