Артикул
Название
Примечание
Количество
|$0
419-15-11051
TRANSMISSION ASS'Y
SN: 20001-UP
1шт.
|$1
419-15-11050
TRANSMISSION ASS'Y
SN: 10001-19999
1шт.
|$2
419-15-11060
TRANSMISSION ASS'Y,(WITH EMERGENCY STEERING)
SN: 10001-UP
1шт.
|$$4
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.2211 TO 2271.
-1шт.
|$4
419-15-15022
CONTROL VALVE ASS'Y,(WA320-1M,1P)
SN: 10001-UP
1шт.
|$5
0
CONTROL VALVE ASS'Y,(WA320-1M,1P)
SN: (10001-20206)
1шт.
|$$7
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.2241 TO 2243.
-1шт.
|$7
419-15-15201
VALVE ASS'Y,UPPER (WA320-1M,1P)
SN: 10001-UP
1шт.
|$8
0
VALVE ASS'Y,UPPER (WA320-1M,1P)
SN: (10001-20206)
1шт.
1
419-15-15711
BODY,(WA320-1M,1P)
SN: 10001-UP
1шт.
1
0
BODY,(WA320-1M,1P)
SN: (10001-20206)
1шт.
3
417-15-15842
ORIFICE
SN: 10001-UP
1шт.
4
419-15-15760
VALVE
SN: 10001-UP
1шт.
5
419-15-15910
SPRING
SN: 10001-UP
1шт.
6
419-15-15770
VALVE,MAIN
SN: 10001-UP
1шт.
7
419-15-15830
PISTON
SN: 10001-UP
1шт.
8
419-15-15920
SPRING
SN: 10001-UP
1шт.
9
419-15-15780
VALVE,PRIORITY
SN: 10001-UP
1шт.
10
419-15-15820
PISTON
SN: 10001-UP
1шт.
11
419-15-15840
VALVE,QUICK RETURN
SN: 10001-UP
1шт.
13
419-15-15510
SPRING
SN: 10001-UP
1шт.
14
419-15-15850
PLUG
SN: 10001-UP
1шт.
15
419-15-15640
PLUG
SN: 10001-UP
1шт.
16
419-15-15810
VALVE,MODULATE
SN: 10001-UP
1шт.
17
419-15-15860
SLEEVE
SN: 10001-UP
1шт.
19
419-15-15940
SPRING
SN: 10001-UP
1шт.
20
419-15-15980
RETAINER
SN: 10001-UP
1шт.
21
419-15-15930
SPRING
SN: 10001-UP
1шт.
22
419-15-15890
PLUG
SN: 10001-UP
1шт.
23
419-15-15790
VALVE,ACCUMULATOR
SN: 10001-UP
1шт.
24
419-15-15960
SPRING
SN: 10001-UP
1шт.
25
419-15-15870
SHAFT
SN: 10001-UP
1шт.
26
419-15-15970
SPRING
SN: 10001-UP
1шт.
27
419-15-15950
SPRING
SN: 10001-UP
1шт.
28
419-15-15730
COVER
SN: 10001-UP
1шт.
29
419-15-15750
GASKET
SN: 10001-UP
1шт.
31
419-15-15720
COVER
SN: 10001-UP
1шт.
32
419-15-15880
ROD,ADJUST
SN: 10001-UP
1шт.
36
419-15-15740
GASKET
SN: 10001-UP
1шт.
40
419-15-16502
VALVE ASS'Y,LOWER (WA320-1M,1P)
SN: 10001-UP
1шт.
40
0
VALVE ASS'Y,LOWER (WA320-1M,1P)
SN: (10001-20206)
1шт.
41
419-15-16811
GASKET,(WA320-1M,1P)
SN: 10001-UP
1шт.
41
0
GASKET,(WA320-1M,1P)
SN: (10001-20206)
1шт.
42
01010-30860
BOLT
SN: 10001-UP
1шт.
44
419-15-16940
HEAD
SN: 10001-UP
1шт.
44
419-15-16960
CASE
SN: 10001-UP
1шт.
48
01642-21016
WASHER
SN: 10001-UP
2шт.
Выбрано товаров: 64
