Запчасти Komatsu WA300-3A-SN КЛАПАН УПРАВЛЕНИЯ ТРАНСМИССИЕЙ (/) (ГЛАВНЫЙ ФИЛЬТР) ТРАНСМИССИЯ

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|1

714-16-10012

TRANSMISSION ASS'Y

SN: 54001-UP

1шт.

|1

714-16-10011

TRANSMISSION ASS'Y

SN: 53001-54000

1шт.

|$$4

THESE ASSEMBLY CONSIST OF SOME FIGS. BE CAREFUL WHEN ORDERING THE PARTS.

-1шт.

|1

714-16-10033

TRANSMISSION ASS'Y,(FOR SNOW REMOVING)

SN: 54001-UP

1шт.

|1

714-16-10032

TRANSMISSION ASS'Y,(FOR SNOW REMOVING)

SN: 53001-54000

1шт.

|1

714-16-17002

VALVE ASS'Y,TRANSMISSION

SN: (84621)-UP

1шт.

|1

0

VALVE ASS'Y,TRANSMISSION

SN: 53001-(84620)

1шт.

|$$9

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-60A0 TO F4350-62A0.

-1шт.

1

419-15-16660

FILTER ASS'Y,PILOT

SN: 53001-UP

1шт.

|1

419-15-16930

ELEMENT

SN: 53001-UP

1шт.

|1

419-15-16940

HEAD

SN: 53001-UP

1шт.

|1

419-15-16950

O-RING

SN: 53001-UP

1шт.

|1

419-15-16960

CASE,FILTER

SN: 53001-UP

1шт.

2

07000-02014

O-RING (K2)

SN: 53001-UP

2шт.

3

01010-81035

BOLT

SN: 53001-UP

2шт.

4

01642-21016

WASHER

SN: 53001-UP

2шт.

5

01602-01030

WASHER,SPRING

SN: 53001-UP

2шт.

6

714-07-17912

GASKET,UPPER VALVE (K2)

SN: (84280)-UP

1шт.

|6

0

GASKET,UPPER VALVE (K2)

SN: 53001-(84279)

1шт.

7

01010-81070

BOLT

SN: 53001-UP

1шт.

8

01010-81045

BOLT

SN: 53001-UP

1шт.
