Запчасти Komatsu WA300-3A ВИЛЫ (LUMBER ЗАХВАТ) РАБОЧЕЕ ОБОРУДОВАНИЕ

1

419-884-1111

CARRIER Z071001A1

SN: 53001-UP

1шт.

2

419-884-1120

FORK Z071001A1

SN: 53001-UP

2шт.

3

419-884-1130

PLATE Z071001A1

SN: 53001-UP

2шт.

4

419-884-1140

PLATE Z071001A1

SN: 53001-UP

4шт.

5

01010-31665

BOLT Z071001A1

SN: 53001-UP

4шт.

6

01580-01613

NUT Z071001A1

SN: 53001-UP

4шт.

7

01643-31645

WASHER Z071001A1

SN: 53001-UP

4шт.

8

01010-62460

BOLT Z071001A1

SN: 53001-UP

4шт.

9

01643-32460

WASHER Z071001A1

SN: 53001-UP

4шт.

10

419-881-1230

PLATE (WELDED)

SN: 53001-UP

2шт.

11

419-881-1240

PLATE (WELDED)

SN: 53001-UP

2шт.

|12

419-881-0010

ARM ASS'Y Z071001A1

SN: 53001-UP

2шт.

12

0

ARM Z071001A1

SN: 53001-UP

1шт.

13

417-70-11860

BUSHING Z071001A1

SN: 53001-UP

2шт.

14

417-09-11120

SEAL,DUST Z071001A1

SN: 53001-UP

4шт.

15

419-881-1190

PLATE (WELDED)

SN: 53001-UP

2шт.

16

419-881-1210

PLATE,L.H. (WELDED)

SN: 53001-UP

1шт.

17

419-881-1220

PLATE,R.H. (WELDED)

SN: 53001-UP

1шт.

18

419-881-1170

PLATE (WELDED)

SN: 53001-UP

3шт.

19

421-70-11280

WASHER Z071001A1

SN: 53001-UP

2шт.

20

01010-31625

BOLT Z071001A1

SN: 53001-UP

2шт.

21

419-881-1260

PIN Z071001A1

SN: 53001-UP

2шт.

22

07020-00000

FITTING,GREASE Z071001A1

SN: 53001-UP

2шт.
