Запчасти Komatsu WA250-1LC МОСТ ASSEMBLY ПЕРЕДН. ВЕДУЩ. ВАЛ

|$0

418-22-10014

AXLE ASSEMBLY, FRONT

1шт.

1

DIFFERENTIAL, FRONT (SEE PG 03-010)

-29шт.

2

07044-13620

PLUG, DRAIN

1шт.

3

07002-03634

O-RING

1шт.

4

419-22-13140

PLUG

2шт.

5

07002-03034

O-RING

2шт.

6

07030-01030

BREATHER

1шт.

7

419-33-11460

BLEEDER

2шт.

8

566-32-11620

CAP

2шт.

9

418-22-13423

HOUSING, LH

1шт.

10

418-22-13412

HOUSING, RH

1шт.

|$11

418-22-13430

HOUSING, RH

1шт.

11

419-22-13140

PLUG, CHECK OIL LEVEL

1шт.

11A

419-22-13140

PLUG, OIL FILL

1шт.

11B

417-22-23250

DIPSTICK, PLUG TYPE (OIL LEVEL)

1шт.

12

07002-03034

O-RING

2шт.

13

01011-61630

BOLT, MOUNT HOUSINGS TO DIFFERENTIAL

28шт.

14

01643-31645

WASHER

28шт.

15

22X-22-13171

PLATE, NAME (LIMITED SUPPLY)

1шт.

16

04418-03060

SCREW

4шт.

|$24

-1шт.

|$21

F1 - USED ON AXLES EQUIPPED WITH FILL PLUG ONLY.

-1шт.

|$25

-1шт.

|$23

F2 - USED ON AXLES EQUIPPED WITH PLUG TYPE DIPSTICK ONLY.

-1шт.

|$26

-1шт.
