Артикул
Название
Примечание
Количество
|$$1
SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.
-1шт.
|$5
714-11-10003
TRANSMISSION ASS'Y
SN: (68569)-UP
1шт.
|$6
714-11-10002
TRANSMISSION ASS'Y
SN: 53001-(68568)
1шт.
|$7
714-11-10043
TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)
SN: (68573)-UP
1шт.
|$8
714-11-10042
TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)
SN: 53001-(68572)
1шт.
|$$6
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-68A0.
-1шт.
|$10
714-11-15031
VALVE ASS'Y
SN: (68611)-UP
1шт.
|$11
714-11-15030
CONTROL VALVE ASS'Y
SN: (67749)-(68610)
1шт.
|$$9
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-60A0 TO F4350-62A0.
-1шт.
|$13
714-11-16200
VALVE ASS'Y,LOWER
SN: (67749)-UP
1шт.
|$$11
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-61A0A AND 62A0A.
-1шт.
|$15
714-11-16900
VALVE ASS'Y,SOLENOID
SN: (67749)-UP
1шт.
1
714-11-16800
BODY ASS'Y,SOLENOID
SN: (67749)-UP
1шт.
2
714-11-16830
SOLENOID VALVE
SN: (67749)-UP
2шт.
2A
714-11-16850
O-RING (K2)
SN: (67749)-UP
1шт.
3
714-11-16840
SOLENOID VALVE
SN: (67749)-UP
2шт.
3A
714-11-16850
O-RING (K2)
SN: (67749)-UP
1шт.
4
714-11-16811
BRACKET
SN: (67749)-UP
1шт.
13
195-30-34260
WASHER
SN: (67749)-UP
1шт.
14
419-06-12840
PLATE
SN: 53001-UP
1шт.
16
419-15-16811
GASKET (K2)
SN: 53001-UP
1шт.
17
01010-80860
BOLT
SN: 53001-UP
1шт.
23
01642-21016
WASHER
SN: 53001-UP
2шт.
Выбрано товаров: 40
