Запчасти Komatsu WA1200-3 КЛАПАН УПРАВЛЕНИЯ ТРАНСМИССИЕЙ ГИДРОТРАНСФОРМАТОР И ТРАНСМИССИЯ

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|$14

42C-13-10014

TORQUE FLOW A.

SN: 50089-UP

1шт.

|$15

0

TORQUE FLOW A.

SN: 50081-50088

1шт.

|$16

0

TORQUE FLOW A.

SN: (50081-50087)

1шт.

|$17

0

TORQUE FLOW A.

SN: 50073-50080

1шт.

|$18

0

TORQUE FLOW A.

SN: (50073-50074)

1шт.

|$19

0

TORQUE FLOW A.

SN: 50064-50072

1шт.

|$20

42C-13-10008

TORQUE FLOW A.

SN: 50060-50063

1шт.

|$21

0

TORQUE FLOW A.

SN: (50060-50061)

1шт.

|$22

0

TORQUE FLOW A.

SN: 50036-50059

1шт.

|$23

0

TORQUE FLOW A.

SN: (50036-50051)

1шт.

|$24

0

TORQUE FLOW A.

SN: (1021)-050035

1шт.

|$25

0

TORQUE FLOW A.

SN: (1014)-(1020)

1шт.

|$26

0

TORQUE FLOW A.

SN: 50001-(1013)

1шт.

|$$15

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.F4310-51A0 TO F4320-72A0.

-1шт.

|$39

42C-15-11012

TRANSMISSION ASS'Y

SN: 50089-UP

1шт.

|$40

0

TRANSMISSION ASS'Y

SN: 50081-50088

1шт.

|$41

0

TRANSMISSION ASS'Y

SN: (50081-50087)

1шт.

|$42

0

TRANSMISSION ASS'Y

SN: 50073-50080

1шт.

|$43

0

TRANSMISSION ASS'Y

SN: (50073-50074)

1шт.

|$44

0

TRANSMISSION ASS'Y

SN: 50064-50072

1шт.

|$45

42C-15-11006

TRANSMISSION ASS'Y

SN: 50036-50063

1шт.

|$46

0

TRANSMISSION ASS'Y

SN: (50036-50061)

1шт.

|$47

0

TRANSMISSION ASS'Y

SN: (50036-50051)

1шт.

|$48

0

TRANSMISSION ASS'Y

SN: (1014)-050035

1шт.

|$49

0

TRANSMISSION ASS'Y

SN: 50001-(1013)

1шт.

|$$27

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.F4320-51A0 TO F4320-72A0.

-1шт.

|$59

42C-15-15013

VALVE ASS'Y

SN: 50081-UP

1шт.

|$60

42C-15-15012

VALVE ASS'Y

SN: 50001-50080

1шт.

|$61

0

VALVE ASS'Y

SN: (50001-(1010))

1шт.

|$$31

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4320-62A0 TO F4320-66A0.

-1шт.

1

42C-15-15161

VALVE SEAT

SN: 50001-UP

1шт.

1

0

VALVE SEAT

SN: (50001-50080)

1шт.

2

19M-15-15180

SEAT

SN: 50001-UP

1шт.

3

07042-80312

PLUG

SN: 50001-UP

4шт.

4

07043-70312

PLUG

SN: 50001-UP

3шт.

5

07043-70415

PLUG

SN: 50001-UP

1шт.

6

07042-80617

PLUG

SN: 50001-UP

2шт.

7

07000-73032

O-RING (K7)

SN: 50001-UP

2шт.

8

07000-73048

O-RING (K7)

SN: 50001-UP

1шт.

9

07000-72018

O-RING (K7)

SN: 50001-UP

1шт.

10

01010-81065

BOLT

SN: 50001-UP

2шт.

11

01643-31032

WASHER

SN: 50001-UP

2шт.

12

42C-15-15602

VALVE ASS'Y,(SEE FIG. F4320-63A0)

SN: 50001-UP

3шт.

12

0

ECMV ASS'Y,(SEE FIG. F4320-63A0)

SN: (50001-(1010))

3шт.

13

07000-72018

O-RING (K7)

SN: 50001-UP

7шт.

14

07000-72021

O-RING (K7)

SN: 50001-UP

8шт.

15

10E-60-25120

BOLT

SN: 50001-UP

4шт.

16

01643-30823

WASHER

SN: 50001-UP

4шт.

17

42C-15-15702

VALVE ASS'Y,(SEE FIG. F4320-64A0)

SN: 50001-UP

2шт.

17

0

ECMV ASS'Y,(SEE FIG. F4320-64A0)

SN: (50001-(1010))

2шт.

18

42C-15-15501

VALVE ASS'Y,(SEE FIG. F4320-65A0)

SN: 50081-UP

2шт.

18

42C-15-15500

VALVE ASS'Y,(SEE FIG. F4320-65A0)

SN: 50001-50080

2шт.

19

42C-15-15901

VALVE ASS'Y,(SEE FIG. F4320-66A0)

SN: 50081-UP

1шт.

19

42C-15-15900

VALVE,(SEE FIG. F4320-66A0)

SN: 50001-50080

1шт.

20

07000-72018

O-RING (K7)

SN: 50001-UP

6шт.

21

07000-72021

O-RING (K7)

SN: 50001-UP

3шт.

22

42C-15-15510

BOLT

SN: 50081-UP

6шт.

22

6138-11-4880

BOLT

SN: 50001-50080

6шт.

23

42C-15-15530

WASHER

SN: 50081-UP

6шт.

23

01643-30823

WASHER

SN: 50001-50080

6шт.

24

04530-11018

BOLT

SN: 50001-UP

2шт.

25

0

PLATE,(LIMITED SUPPLY)

SN: (101138)-UP

1шт.

25

0

PLATE, NAME,(LIMITED SUPPLY)

SN: 50001-(101137)

1шт.
