Запчасти Komatsu WA120-1LC МОСТ ASSEMBLY ПЕРЕДН. ВЕДУЩ. ВАЛ

|$0

416-22-10010

AXLE ASSEMBLY, FRONT

1шт.

|$1

417-22-10004

AXLE ASSEMBLY, FRONT

1шт.

1

DIFFERENTIAL, FRONT (SEE PG 03-010)

-29шт.

2

07044-13620

PLUG, DRAIN

1шт.

3

07002-03634

O-RING, DRAIN PLUG

1шт.

4

419-22-13140

PLUG

2шт.

5

07002-03034

O-RING

2шт.

6

419-33-11460

BLEEDER

2шт.

7

566-32-11620

CAP, BLEEDER

2шт.

8

417-22-13223

HOUSING, LH

1шт.

|$10

417-22-23220

HOUSING, LH

1шт.

9

417-22-13213

HOUSING, RH

1шт.

|$12

417-22-23210

HOUSING, RH

1шт.

10

419-22-13140

PLUG, CHECK OIL LEVEL

2шт.

10A

419-22-13140

PLUG, OIL FILL

1шт.

10B

417-22-23250

DIPSTICK, PLUG TYPE (OIL LEVEL)

1шт.

11

07002-03034

O-RING, OIL LEVEL AND FILL PLUG

3шт.

11A

07002-03034

O-RING, DIPSTICK

1шт.

12

417-22-13311

ADAPTER, BREATHER

1шт.

13

07030-01030

BREATHER

1шт.

14

01011-61625

BOLT, HOUSINGS TO DIFFERENTIAL

28шт.

15

01643-31645

WASHER

28шт.

16

22X-22-13171

PLATE, NAME (LIMITED SUPPLY)

1шт.

17

04418-03060

SCREW

4шт.

|$32

-1шт.

|$25

F1 - AXLE EQUIPPED WITH FILL PLUG - S/N NOT AVAILABLE.

-1шт.

|$33

-1шт.

|$27

F2 - AXLE EQUIPPED WITH PLUG TYPE DIPSTICK - S/N NOT AVAILABLE.

-1шт.

|$34

-1шт.

|$29

F3 - USED ON AXLES EQUIPPED WITH FILL PLUG ONLY.

-1шт.

|$35

-1шт.

|$31

F4 - USED ON AXLES EQUIPPED WITH PLUG TYPE DIPSTICK ONLY.

-1шт.

|$36

-1шт.
