Запчасти Komatsu 450FXL-1 R-A ПЕРЕДН. ЛЕНИВЕЦ НИЖН.CARRIAGE

|$0

208-30-00701

IDLER ASSEMBLY

SN: A10001--UP

2шт.

1

208-30-73611

IDLER, FRONT

SN: A10001--UP

1шт.

2

208-30-11560

BUSHING

SN: A10001--UP

2шт.

3

208-30-53130

SHAFT

SN: A10001--UP

1шт.

4

07040-13618

PLUG

SN: A10001--UP

1шт.

5

07002-13634

O-RING

SN: A10001--UP

1шт.

6

07000-12090

O-RING

SN: A10001--UP

2шт.

|$7

21T-30-00110

FLOATING SEAL ASSEMBLY

SN: A10001--UP

2шт.

7

NSS

O-RING

SN: A10001--UP

2шт.

8

NSS

SEAL

SN: A10001--UP

2шт.

9

208-30-53150

SUPPORT, L.H.

SN: A10001--UP

2шт.

10

208-30-53160

SUPPORT, R.H.

SN: A10001--UP

2шт.

11

170-30-13331

BOLT

SN: A10001--UP

2шт.

12

01580-11613

NUT

SN: A10001--UP

2шт.

13

01643-31645

WASHER

SN: A10001--UP

2шт.
