Запчасти Komatsu WB140-2N ЭЛЕКТРИЧ. ОБОРУД-Е ОСНОВНАЯ РАМА И ЕЕ ЧАСТИ

21

655 621 40

Cable union DN 10

22

655 622 40

Cable union DN 12

23

655 623 40

Cable union DN 17

24

655 624 40

Cable union DN 23

25

655 697 40

Cable union DN 29

26

655 835 40

Cable union DN 36

27

504 546 99

Cable nut

28

502 826 98

Cable nut

29

502 828 98

Cable nut

30

501 677 98

Cable nut

31

501 654 98

Cable nut

32

502 589 98

Cable nut

33

907 177 40

Cable protection hose DN 10

34

907 178 40

Cable protection hose DN 12

35

907 179 40

Cable protection hose DN 17

36

907 180 40

Cable protection hose DN 23

37

907 213 40

Cable protection hose DN 29

38

907 214 40

Cable protection hose DN 36

39

515 213 98

Cable 1 mm2

40

655 877 40

Cable 2x0,75 qmm

50

906 413 40

Cable channel

51

906 414 40

Cable channel

52

307 727 99

Bolt

53

350 762 99

Washer

54

919 436 40

Retainer

55

919 437 40

Retainer

56

921 509 40

Retainer

57

346 499 99

Lock washer

58

461 933 40

Ground strap 70x300

60

940 008 40

Temp.-Datalogger

61

940 009 40

Battery

62

940 010 40

Sensor Cable

63

940 011 40

Windows-Software

64

940 012 40

PC-Cable

65

940 007 40

Switch cabinet
