Запчасти Komatsu WB140-2N OPERATION ПАНЕЛЬ ЭЛЕКТРИЧ. ОБОРУД-Е
№
Артикул
Название
Примечание
Количество
01
946 908 40
Switch plate
02
943 251 40
Instrumental board
03
933 358 40
Shift plate
04
551 272 40
Ignition switch
05
764 535 73
Key
06
896 716 40
Hour meter
07
515 105 40
Analog indicator
08
440 129 40
Volt meter
09
769 517 73
Ampere meter
10
324 400 40
Turn switch
11
324 401 40
Turn switch 1-stage
12
324 402 40
Turn switch 2-stage
13
399 702 40
Turn switch
14
440 369 40
Turn switch 3-stage
15
896 473 40
Toggle switch
16
515 299 40
Luminous touch contact
17
515 300 40
Push hood
18
414 866 40
Ignition switch
19
698 239 73
Key
20
490 518 40
Alarm transmitter
21
592 661 40
Bulb
22
631 556 40
Graphical symbol
23
794 955 73
Volt meter
24
891 033 40
Emergency switch off assy.
25
655 686 40
Impact key
26
655 676 40
Spring element
27
635 115 40
Contact element
28
635 652 40
Contact element
29
796 187 73
Cigarette lighter
30
919 429 40
Socket plate
31
440 307 99
Socket
33
940 047 40
Alarm transmitter
34
896 732 40
Console ashtray
35
793 765 73
Switch
36
940 835 40
Radio
41
505 940 99
Assembly rail
42
906 768 40
Through clamp 6,0
43
906 772 40
Cover plate
44
515 213 40
Cable 1.0
45
515 214 40
Cable 2.5
46
655 675 40
Cable 6.0
47
906 022 40
Cable 4.0
48
270 873 40
Cable channel
49
796 442 73
Data and Diagnostic tool
50
796 443 73
Cable set
51
906 770 40
Through clamp 10,0
52
906 774 40
Cover plate
53
356 265 40
Clamp
55
440 151 99
Tab 1.5
56
055 115 40
Tab 1.5 - 2.5
57
697 269 73
Tab 4.0 - 6.0 yellow
58
507 382 99
Bulb 2 W
59
507 384 99
Bulb 3 W
60
966 740
Socket
61
966 975
Socket
62
906 769 40
Through clamp 16,0
63
906 773 40
Cover plate
64
659 872 40
Data cable ECS /display - X27
66
906 612 40
Through clamp 2.5
67
906 613 40
Cover plate
68
906 630 40
Protective wire clip 2.5
69
898 668 40
Socket assy
70
659 871 40
Connection cable assy
72
927 582 40
Cable assy.
73
794 380 73
Lamp
74
794 381 73
Bulb
Выбрано товаров: 66
