|1
6128-11-1102
CYLINDER HEAD ASS'Y,WITH VALVE
SN: 36496-UP
3шт.
|1
0
CYLINDER HEAD ASS'Y,WITH VALVE
SN: .-36495
3шт.
|1
0
CYLINDER HEAD ASS'Y,WITH VALVE
SN: 25887-.
3шт.
|1
6128-11-1022
CYLINDER HEAD ASS'Y,VALVE LESS
SN: 36496-UP
1шт.
|1
0
CYLINDER HEAD ASS'Y,VALVE LESS
SN: .-36495
1шт.
|1
0
CYLINDER HEAD ASS'Y,VALVE LESS
SN: 25887-.
1шт.
1
0
HEAD,CYLINDER
SN: 36496-UP
1шт.
|1
0
HEAD,CYLINDER
SN: 25887-36495
1шт.
2
6128-11-1130
SLEEVE
SN: 25887-UP
2шт.
3
6127-11-1141
GUIDE,VALVE
SN: 25887-UP
4шт.
4
6127-11-1341
GUIDE,VALVE
SN: 25887-UP
8шт.
5
6127-11-1325
SEAT,EXHAUST VALVE (STD)
SN: 36496-UP
4шт.
|5
0
SEAT,EXHAUST VALVE (STD)
SN: 25887-36495
4шт.
|5
6127-19-1325
SEAT¤ 0.25MM,EXHAUST VALVE (OS)
SN: 36496-UP
4шт.
|5
0
SEAT¤ 0.25MM,EXHAUST VALVE (OS)
SN: 25887-36495
4шт.
|5
6127-18-1325
SEAT¤ 0.50MM,EXHAUST VALVE (OS)
SN: 36496-UP
4шт.
|5
0
SEAT¤ 0.50MM,EXHAUST VALVE (OS)
SN: 25887-36495
4шт.
|5
6127-17-1325
SEAT¤ 0.75MM,EXHAUST VALVE (OS)
SN: 36496-UP
4шт.
|5
0
SEAT¤ 0.75MM,EXHAUST VALVE (OS)
SN: 25887-36495
4шт.
|5
6127-16-1325
SEAT¤ 1.00MM,EXHAUST VALVE (OS)
SN: 36496-UP
4шт.
|5
0
SEAT¤ 1.00MM,EXHAUST VALVE (OS)
SN: 25887-36495
4шт.
6
6127-11-1335
SEAT,INTAKE VALVE (STD)
SN: 25887-UP
4шт.
|6
6127-19-1335
SEAT¤ 0.25MM,INTAKE VALVE (OS)
SN: 25887-UP
4шт.
|6
6127-18-1335
SEAT¤ 0.50MM,INTAKE VALVE (OS)
SN: 25887-UP
4шт.
|6
6127-17-1335
SEAT¤ 0.75MM,INTAKE VALVE (OS)
SN: 25887-UP
4шт.
|6
6127-16-1335
SEAT¤ 1.00MM,INTAKE VALVE (OS)
SN: 25887-UP
4шт.
7
07046-43016
PLUG
SN: 36496-UP
13шт.
|7
0
PLUG
SN: 25887-36495
13шт.
8
07046-42516
PLUG
SN: 36496-UP
2шт.
|8
0
PLUG
SN: 25887-36495
2шт.
9
6127-41-4113
VALVE,INTAKE
SN: 25887-UP
4шт.
10
6127-41-4214
VALVE,EXHAUST
SN: 36496-UP
4шт.
|10
0
VALVE,EXHAUST
SN: 25887-36495
4шт.
11
6127-41-4410
SPRING,VALVE
SN: 25887-UP
8шт.
12
6127-41-4530
SEAT,VALVE
SN: 25887-UP
4шт.
13
6127-41-4541
SEAL,VALVE STEM (K1)
SN: 25887-UP
4шт.
|14
6127-40-4501
VALVE COTTER ASS'Y
SN: 25887-UP
8шт.
14
6127-41-4522
COTTER
SN: 25887-UP
2шт.
15
6127-41-4510
SEAT,VALVE
SN: 25887-UP
1шт.
|16
6127-11-1087
GASKET ASS'Y,CYLINDER HEAD (K1)
SN: 25887-UP
3шт.
16
0
GASKET,CYLINDER HEAD
SN: 25887-UP
1шт.
17
6127-11-1827
SEAL,RING
SN: 36496-UP
2шт.
|17
0
RING,SEAL
SN: .-36495
2шт.
|17
0
RING,SEAL
SN: 25887-.
2шт.
18
6127-11-1830
GROMMET
SN: 25887-UP
1шт.
19
6127-11-1841
GROMMET
SN: 25887-UP
8шт.
20
6127-11-1851
RETAINER
SN: 25887-UP
8шт.
21
6127-11-1410
COVER
SN: 25887-UP
3шт.
22
6110-61-6832
GASKET (K1)
SN: 55329-UP
3шт.
|22
0
GASKET (K1)
SN: 25887-55328
3шт.
23
01010-81030
BOLT
SN: 25887-UP
4шт.
24
01602-01030
WASHER,SPRING
SN: 25887-UP
4шт.
25
6127-11-1612
BOLT
SN: 25887-UP
30шт.
26
6127-11-1620
WASHER
SN: 25887-UP
30шт.
27
6127-41-5614
CROSSHEAD
SN: 25887-UP
12шт.
28
6127-41-5641
SCREW,ADJUSTING
SN: 25887-UP
12шт.
29
6127-41-5630
NUT
SN: 25887-UP
12шт.
|1
6128-11-1102
CYLINDER HEAD ASS'Y,WITH VALVE
SN: 36496-UP
3шт.
|1
0
CYLINDER HEAD ASS'Y,WITH VALVE
SN: .-36495
3шт.
|1
0
CYLINDER HEAD ASS'Y,WITH VALVE
SN: 25887-.
3шт.
|1
6128-11-1022
CYLINDER HEAD ASS'Y,VALVE LESS
SN: 36496-UP
1шт.
|1
0
CYLINDER HEAD ASS'Y,VALVE LESS
SN: .-36495
1шт.
|1
0
CYLINDER HEAD ASS'Y,VALVE LESS
SN: 25887-.
1шт.
1
0
HEAD,CYLINDER
SN: 36496-UP
1шт.
|1
0
HEAD,CYLINDER
SN: 25887-36495
1шт.
2
6128-11-1130
SLEEVE
SN: 25887-UP
2шт.
3
6127-11-1141
GUIDE,VALVE
SN: 25887-UP
4шт.
4
6127-11-1341
GUIDE,VALVE
SN: 25887-UP
8шт.
5
6127-11-1325
SEAT,EXHAUST VALVE (STD)
SN: 36496-UP
4шт.
|5
0
SEAT,EXHAUST VALVE (STD)
SN: 25887-36495
4шт.
|5
6127-19-1325
SEAT¤ 0.25MM,EXHAUST VALVE (OS)
SN: 36496-UP
4шт.
|5
0
SEAT¤ 0.25MM,EXHAUST VALVE (OS)
SN: 25887-36495
4шт.
|5
6127-18-1325
SEAT¤ 0.50MM,EXHAUST VALVE (OS)
SN: 36496-UP
4шт.
|5
0
SEAT¤ 0.50MM,EXHAUST VALVE (OS)
SN: 25887-36495
4шт.
|5
6127-17-1325
SEAT¤ 0.75MM,EXHAUST VALVE (OS)
SN: 36496-UP
4шт.
|5
0
SEAT¤ 0.75MM,EXHAUST VALVE (OS)
SN: 25887-36495
4шт.
|5
6127-16-1325
SEAT¤ 1.00MM,EXHAUST VALVE (OS)
SN: 36496-UP
4шт.
|5
0
SEAT¤ 1.00MM,EXHAUST VALVE (OS)
SN: 25887-36495
4шт.
6
6127-11-1335
SEAT,INTAKE VALVE (STD)
SN: 25887-UP
4шт.
|6
6127-19-1335
SEAT¤ 0.25MM,INTAKE VALVE (OS)
SN: 25887-UP
4шт.
|6
6127-18-1335
SEAT¤ 0.50MM,INTAKE VALVE (OS)
SN: 25887-UP
4шт.
|6
6127-17-1335
SEAT¤ 0.75MM,INTAKE VALVE (OS)
SN: 25887-UP
4шт.
|6
6127-16-1335
SEAT¤ 1.00MM,INTAKE VALVE (OS)
SN: 25887-UP
4шт.
7
07046-43016
PLUG
SN: 36496-UP
13шт.
|7
0
PLUG
SN: 25887-36495
13шт.
8
07046-42516
PLUG
SN: 36496-UP
2шт.
|8
0
PLUG
SN: 25887-36495
2шт.
9
6127-41-4113
VALVE,INTAKE
SN: 25887-UP
4шт.
10
6127-41-4214
VALVE,EXHAUST
SN: 36496-UP
4шт.
|10
0
VALVE,EXHAUST
SN: 25887-36495
4шт.
11
6127-41-4410
SPRING,VALVE
SN: 25887-UP
8шт.
12
6127-41-4530
SEAT,VALVE
SN: 25887-UP
4шт.
13
6127-41-4541
SEAL,VALVE STEM (K1)
SN: 25887-UP
4шт.
|14
6127-40-4501
VALVE COTTER ASS'Y
SN: 25887-UP
8шт.
14
6127-41-4522
COTTER
SN: 25887-UP
2шт.
15
6127-41-4510
SEAT,VALVE
SN: 25887-UP
1шт.
|16
6127-11-1087
GASKET ASS'Y,CYLINDER HEAD (K1)
SN: 25887-UP
3шт.
16
0
GASKET,CYLINDER HEAD
SN: 25887-UP
1шт.
17
6127-11-1827
SEAL,RING
SN: 36496-UP
2шт.
|17
0
RING,SEAL
SN: .-36495
2шт.
|17
0
RING,SEAL
SN: 25887-.
2шт.
18
6127-11-1830
GROMMET
SN: 25887-UP
1шт.
19
6127-11-1841
GROMMET
SN: 25887-UP
8шт.
20
6127-11-1851
RETAINER
SN: 25887-UP
8шт.
21
6127-11-1410
COVER
SN: 25887-UP
3шт.
22
6110-61-6832
GASKET (K1)
SN: 55329-UP
3шт.
|22
0
GASKET (K1)
SN: 25887-55328
3шт.
23
01010-81030
BOLT
SN: 25887-UP
4шт.
24
01602-01030
WASHER,SPRING
SN: 25887-UP
4шт.
25
6127-11-1612
BOLT
SN: 25887-UP
30шт.
26
6127-11-1620
WASHER
SN: 25887-UP
30шт.
27
6127-41-5614
CROSSHEAD
SN: 25887-UP
12шт.
28
6127-41-5641
SCREW,ADJUSTING
SN: 25887-UP
12шт.
29
6127-41-5630
NUT
SN: 25887-UP
12шт.
