Запчасти Komatsu S6D105-1MM ГОЛОВКА ЦИЛИНДРОВ ГОЛОВКА ЦИЛИНДРОВ

|$0

6137-12-1020

CYLINDER HEAD ASS'Y,WITH VALVE

SN: 80070-UP

1шт.

|$1

6137-12-1200

CYLINDER HEAD ASS'Y,VALVE LESS

SN: 80070-UP

1шт.

1

0

HEAD,CYLINDER

SN: 80070-UP

1шт.

2

6136-11-1130

SLEEVE,HOLDER

SN: 80070-UP

6шт.

3

6138-12-1310

SEAT,INTAKE VALVE (STD)

SN: 80070-UP

6шт.

3

6138-19-1310

SEAT, 0.25MM,INTAKE VALVE (OS)

SN: 80070-UP

6шт.

3

6138-18-1310

SEAT, 0.50MM,INTAKE VALVE (OS)

SN: 80070-UP

6шт.

3

6138-17-1310

SEAT, 0.75MM,INTAKE VALVE (OS)

SN: 80070-UP

6шт.

3

6138-16-1310

SEAT, 1.00MM,INTAKE VALVE (OS)

SN: 80070-UP

6шт.

4

6136-12-1320

SEAT,EXHAUST VALVE (STD)

SN: 80070-UP

6шт.

4

6136-19-1420

SEAT, 0.25MM,EXHAUST VALVE (OS)

SN: 80070-UP

6шт.

4

6136-18-1420

SEAT, 0.50MM,EXHAUST VALVE (OS)

SN: 80070-UP

6шт.

4

6136-17-1420

SEAT, 0.75MM,EXHAUST VALVE (OS)

SN: 80070-UP

6шт.

4

6136-16-1420

SEAT, 1.00MM,EXHAUST VALVE (OS)

SN: 80070-UP

6шт.

5

0

GUIDE,VALVE

SN: 80070-UP

12шт.

6

07046-42816

PLUG

SN: 80070-UP

13шт.

7

07046-44016

PLUG

SN: 80070-UP

4шт.

8

07043-50108

PLUG

SN: 80070-UP

7шт.

9

6138-42-4110

VALVE,INTAKE

SN: 80070-UP

6шт.

10

6136-42-4210

VALVE,EXHAUST

SN: 80070-UP

6шт.

11

6136-42-4410

SPRING,VALVE

SN: 80070-UP

12шт.

12

6136-42-4510

GUIDE,SPRING

SN: 80070-UP

12шт.

13

6136-42-4520

COTTER,VALVE

SN: 80070-UP

24шт.

14

6136-41-4530

SEAT,SPRING

SN: 80070-UP

12шт.

15

6136-11-1813

GASKET,HEAD (K1)

SN: 80070-UP

1шт.

15

0

GASKET,HEAD (K1)

SN: (80070-96035)

1шт.

16

6136-12-1610

BOLT

SN: 80070-UP

26шт.

17

6136-11-1910

HANGER,FRONT

SN: 80070-UP

1шт.

18

6136-11-1821

GASKET (K1)

SN: 80070-UP

1шт.

19

6136-11-1930

HANGER,REAR

SN: 80070-UP

1шт.

20

01010-31025

BOLT

SN: 80070-UP

2шт.

21

01602-01030

WASHER,SPRING

SN: 80070-UP

2шт.
