Запчасти Komatsu D85E-SS-2 КОНЕЧНАЯ ПЕРЕДАЧА (ЗВЕЗДОЧКА И ВТУЛКА) СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$1

14Y-27-00011

FINAL DRIVE ASS'Y, L..H.

Field_1: J10241-J11047

1шт.

|$2

14Y-27-00013

FINAL DRIVE ASS'Y, L..H.

Field_1: J11048-J11227

1шт.

|$3

14Y-27-00014

FINAL DRIVE ASS'Y, L..H.

Field_1: J11228-J11257

1шт.

|$4

14Y-27-00015

FINAL DRIVE ASS'Y, L..H.

Field_1: J11258-

1шт.

|$5

14Y-27-00021

FINAL DRIVE ASS'Y, R..H.

Field_1: J10241-J11047

1шт.

|$6

14Y-27-00023

FINAL DRIVE ASS'Y, R..H.

Field_1: J11048-J11227

1шт.

|$7

14Y-27-00024

FINAL DRIVE ASS'Y, R..H.

Field_1: J11228-J11257

1шт.

|$8

14Y-27-00025

FINAL DRIVE ASS'Y, R..H.

Field_1: J11258-

1шт.

1

14Y-27-11412

PINION

Field_1: J10241-

1шт.

2

14X-27-11311

GEAR

Field_1: J10241-J11047

1шт.

|$11

14X-27-11312

GEAR

Field_1: J11048-

1шт.

3

06040-06024

BEARING

Field_1: J10241-J11047

2шт.

|$13

14X-27-11760

BEARING

Field_1: J11048-

2шт.

4

14X-27-11420

COLLAR

Field_1: J10241-

1шт.

5

14X-27-11113

CASE, LH

Field_1: J10241-J11047

1шт.

|$16

14X-27-11115

CASE, LH

Field_1: J11048-

1шт.

|$17

14X-27-11123

CASE, RH

Field_1: J10241-J11047

1шт.

|$18

14X-27-11125

CASE, RH

Field_1: J11048-

1шт.

6

07044-13620

PLUG

Field_1: J10241-

1шт.

7

07002-03634

O-RING

Field_1: J10241-

1шт.

8

14Y-27-11152

COVER, LH

Field_1: J10241-J11047

1шт.

|$22

14Y-27-11155

COVER, LH

Field_1: J11048-J11257

1шт.

|$23

14Y-27-11156

COVER, LH

Field_1: J11258-

1шт.

|$24

14Y-27-11162

COVER, RH

Field_1: J10241-J11047

1шт.

|$25

14Y-27-11165

COVER, RH

Field_1: J11048-J11257

1шт.

|$26

14Y-27-11166

COVER, RH

Field_1: J11258-

1шт.

9

14X-27-11170

O-RING

Field_1: J10241-

2шт.

10

01010-81645

BOLT

Field_1: J10241-

28шт.

11

01643-31645

WASHER

Field_1: J10241-

28шт.

12

14X-27-11710

HUB

Field_1: J10241-J11257

1шт.

|$31

14X-27-11711

HUB

Field_1: J11258-

1шт.

13

14X-27-15112

TEETH

Field_1: J10241-

9шт.

14

154-27-12320

BOLT

Field_1: J10241-

27шт.

15

01803-02228

NUT

Field_1: J10241-

27шт.

16

14X-27-11721

BEARING

Field_1: J10241-

2шт.

17

14X-27-11751

COLLAR

Field_1: J10241-

1шт.

|$37

14X-27-00100

FLOATING SEAL ASS'Y

Field_1: J10241-J11257

1шт.

|$38

14X-27-00101

FLOATING SEAL ASS'Y

Field_1: J11258-

1шт.

18

14X-27-00110

SEAL ASS'Y

Field_1: J10241-J11257

1шт.

|$40

14X-27-00111

SEAL ASS'Y

Field_1: J11258-

1шт.

19

14X-27-00120

O-RING ASS'Y

Field_1: J10241-

1шт.

20

07049-01620

PLUG

Field_1: J10241-

1шт.
