Запчасти Komatsu D85E-SS-2 ПЕРЕДН. ЛЕНИВЕЦ ХОДОВАЯ

|$1

14X-30-00111

IDLER ASS'Y

Field_1: J10001-J10123

2шт.

|$2

14X-30-00160

IDLER ASS'Y

Field_1: J10124-J10240

2шт.

|$3

14X-30-00112

IDLER ASS'Y

Field_1: J10241-J10774

2шт.

|$4

14X-30-00113

IDLER ASS'Y

Field_1: J10775-

2шт.

1

14X-30-12112

IDLER

Field_1: J10001-J10123

1шт.

|$6

14X-30-12113

IDLER

Field_1: J10124-J10888

1шт.

|$7

14X-30-12114

IDLER

Field_1: J10889-

1шт.

2

14X-30-12180

BUSHING

Field_1: J10001-

2шт.

3

14X-30-12162

SHAFT

Field_1: J10124-J10240

1шт.

|$10

14X-30-12163

SHAFT

Field_1: J10241-

1шт.

4

427-15-15910

O-RING

Field_1: J10001-

2шт.

5

14X-30-12360

SUPPORT, LH

Field_1: J10124-J10240

1шт.

|$13

14X-30-12126

SUPPORT, LH

Field_1: J10241-J10774

1шт.

|$14

14X-30-12127

SUPPORT, LH

Field_1: J10775-

1шт.

6

14X-30-12231

PLATE (WELDED)

Field_1: J10001-J10774

1шт.

|$16

14X-30-12232

PLATE (WELDED)

Field_1: J10775-

1шт.

7

14X-30-12261

PLATE (WELDED)

Field_1: J10124-J10240

1шт.

|$18

14X-30-12262

PLATE (WELDED)

Field_1: J10241-J10774

1шт.

|$19

14X-30-12263

PLATE (WELDED)

Field_1: J10775-

1шт.

8

14X-30-12380

SUPPORT, RH

Field_1: J10124-J10240

1шт.

|$21

14X-30-12146

SUPPORT, RH

Field_1: J10241-J10774

1шт.

|$22

14X-30-12147

SUPPORT, RH

Field_1: J10775-

1шт.

9

14X-30-12231

PLATE (WELDED)

Field_1: J10001-J10774

1шт.

|$24

14X-30-12232

PLATE (WELDED)

Field_1: J10775-

1шт.

10

14X-30-12262

PLATE (WELDED)

Field_1: J10001-J10774

1шт.

|$26

14X-30-12263

PLATE (WELDED)

Field_1: J10775-

1шт.

|$27

205-30-00052

FLOATING SEAL A

Field_1: J10001-

2шт.

11

205-30-00150

SEAL RING ASS'Y

Field_1: J10001-

1шт.

12

205-30-00061

O-RING SET

Field_1: J10001-J10240

1шт.

13

130-30-13170

BOLT

Field_1: J10001-

2шт.

14

01582-11613

NUT

Field_1: J10001-

2шт.

15

01643-31645

WASHER

Field_1: J10001-

2шт.

16

07052-31217

PLUG

Field_1: J10001-

2шт.

17

14X-30-12223

COVER

Field_1: J10001-J10774

4шт.

|$35

14X-30-12224

COVER

Field_1: J10775-

4шт.

18

14X-30-12252

SHIM

Field_1: J10241-

20шт.

19

01010-81645

BOLT

Field_1: J10001-

16шт.

20

01643-31645

WASHER

Field_1: J10001-

16шт.
