Запчасти Komatsu D61EX-15 H.S.S.(КЛАПАН) F [СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА]

|1

134-22-70000

POWER LINE ASSEMBLY

SN: B40001-UP

1шт.

|$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2300-51A0 TO F2300-64A0.

-1шт.

|1

134-22-70010

POWER LINE ASSEMBLY, (FOR REAR ATTACHMENT)

SN: B40001-UP

1шт.

|$4

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2300-51A1 TO F2300-64A1.

-1шт.

|1

134-22-71000

STEERING ASSEMBLY

SN: B40001-UP

1шт.

|$6

THIS ASSEMBLY CONSISTS OF ALL PART SHOWN IN FIGS.F2300-52A0 TO F2300-55A0.

-1шт.

|1

134-22-72300

COVER ASSEMBLY

SN: B40001-UP

1шт.

|1

134-40-62100

VALVE ASSEMBLY

SN: B40001-UP

1шт.

1

14Z-40-11210

BODY

SN: B40001-UP

1шт.

2

07043-70312

PLUG

SN: B40001-UP

1шт.

3

07042-70312

PLUG

SN: B40001-UP

1шт.

4

14Z-40-11320

GUIDE

SN: B40001-UP

1шт.

5

14Z-40-11330

SHAFT

SN: B40001-UP

1шт.

6

04025-00316

PIN

SN: B40001-UP

1шт.

7

14Z-40-11340

GUIDE

SN: B40001-UP

1шт.

8

195-40-31540

PISTON

SN: B40001-UP

1шт.

9

14Z-40-11310

VALVE

SN: B40001-UP

1шт.

10

14Z-40-11380

SPRING

SN: B40001-UP

1шт.

11

14Z-40-11371

SPRING

SN: B40001-UP

1шт.

12

14Z-40-11350

SHIM 0.05MM

SN: B40001-UP

5шт.

13

14Z-40-11610

SPOOL

SN: B40001-UP

1шт.

14

565-62-11270

SPRING

SN: B40001-UP

1шт.

15

14Z-40-11360

PLUG

SN: B40001-UP

2шт.

16

07002-32434

O-RING

SN: B40001-UP

2шт.

17

14Z-40-11220

COVER

SN: B40001-UP

2шт.

18

113-15-29110

SEAL

SN: B40001-UP

2шт.

19

01010-80620

BOLT

SN: B40001-UP

4шт.

20

01643-30623

WASHER

SN: B40001-UP

4шт.

21

07002-33034

O-RING

SN: B40001-UP

2шт.

22

14Z-40-12100

VALVE ASSEMBLY

SN: B40001-UP

1шт.

23

01010-81290

BOLT

SN: B40001-UP

4шт.

24

01643-31232

WASHER

SN: B40001-UP

4шт.

25

07000-72018

O-RING

SN: B40001-UP

4шт.

26

07000-73032

O-RING

SN: B40001-UP

1шт.
