Запчасти Komatsu D375A-5D КОНЕЧНАЯ ПЕРЕДАЧА (ЗВЕЗДОЧКА ВТУЛКА) (ЛЕВ.) СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$2

195-27-00651

FINAL DRIVE G.LH -50,L.H.

SN: 18349-UP

1шт.

|$3

195-27-00426

FINAL DRIVE ASS'Y

SN: 17743-18348

1шт.

|$$3

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2380-01A1 TO 03A1.

-1шт.

1

195-27-34111

HUB

SN: 17743-UP

1шт.

2

195-27-33111

TEETH

SN: 17743-UP

5шт.

3

195-27-33130

BOLT

SN: 17743-UP

25шт.

4

195-27-33141

NUT

SN: 17743-UP

25шт.

5

195-27-34340

COVER

SN: 17743-UP

1шт.

6

07000-45500

O-RING

SN: 17743-UP

1шт.

7

07049-01215

PLUG

SN: 17743-UP

2шт.

8

01010-81230

BOLT

SN: 17743-UP

10шт.

9

01643-31232

WASHER

SN: 17743-UP

10шт.

10

195-27-34120

COVER

SN: 17743-UP

1шт.

11

198-27-31420

PLUG

SN: 17743-UP

1шт.

12

07002-53634

O-RING

SN: 17743-UP

1шт.

13

07049-01620

PLUG

SN: 17743-UP

2шт.

14

07000-45455

O-RING

SN: 17743-UP

1шт.

15

01010-81650

BOLT

SN: 17743-UP

18шт.

16

01643-31645

WASHER

SN: 17743-UP

18шт.

17

195-27-34171

COLLAR

SN: 17743-UP

1шт.

18

195-09-18410

BEARING

SN: 17743-UP

1шт.

19

195-27-31390

HOLDER

SN: 17743-UP

1шт.

20

01010-81650

BOLT

SN: 17743-UP

18шт.

21

195-27-31581

HUB

SN: 17743-UP

1шт.

22

195-27-34280

PLATE

SN: 17743-UP

1шт.

23

195-27-34270

SPACER

SN: 17743-UP

1шт.

24

01010-81635

BOLT

SN: 17743-UP

8шт.

|$37

195-27-00201

FLOATING SEAL ASS'Y

SN: 17743-UP

1шт.

25

0

SEAL

SN: 17743-UP

2шт.

26

0

O-RING

SN: 17743-UP

2шт.

|$1

195-22-00120

STEERING ASS'Y,(B)

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2370-51A1 TO F2370-59A1.

|$5

195-22-00304

CLUTCH AND BRAKE A.

|$6

195-22-00303

CLUTCH AND BRAKE A.

|$7

195-22-00302

CLUTCH AND BRAKE A.,(B)

|$$6

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2370-54A1 AND F2370-55A1.

1

195-22-83110

CASE

1

195-22-13113

CASE

1

195-22-13112

CASE

2

07040-12012

PLUG

2

07042-70312

PLUG

3

07040-12012

PLUG

3

07042-30415

PLUG

4

195-22-13560

PLUG

4

195-22-13510

PLUG

5

17M-22-47820

O-RING

6

195-22-13143

SPRING ASS'Y

6

195-22-13141

SPRING

7

07000-42018

O-RING

8

01011-81235

BOLT

9

01643-31232

WASHER

10

195-22-13160

PIN

11

195-22-13170

PIN

12

195-22-13370

PLATE

13

195-22-73340

DISC

13

195-22-13341

DISC

14

195-15-12880

SPRING

15

195-22-13182

STOPPER

16

04020-01228

PIN,DOWEL

17

01011-61610

BOLT

18

01643-31645

WASHER

19

07000-42018

O-RING

20

195-22-13550

SPRING ASS'Y

20

195-22-13142

SPRING

21

01011-81240

BOLT

22

01643-31232

WASHER

23

195-22-15121

HUB

23

195-22-15120

HUB

24

01010-81035

BOLT

25

01643-31032

WASHER

26

195-22-15150

PIN

27

195-22-15140

PIN

28

195-22-13370

PLATE

29

195-22-13441

DISC

30

195-15-12880

SPRING

31

195-22-15130

STOPPER

32

04020-01228

PIN,DOWEL

33

01011-61615

BOLT

34

01643-31645

WASHER

35

195-22-13230

PLATE

36

01010-81270

BOLT

37

01643-31232

WASHER
