Артикул
Название
Примечание
Количество
|$$1
SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.
-1шт.
|1
114-15-00036
TRANSMISSION ASS'Y
SN: 47617-UP
1шт.
|1
114-15-00035
TRANSMISSION ASS'Y
SN: 45421-47616
1шт.
|1
114-15-00035
TRANSMISSION ASS'Y,(FOR TWO LEVERS STEERING)
SN: 45421-UP
1шт.
|1
0
TRANSMISSION ASS'Y
SN: 45001-45420
1шт.
|$$6
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO F2320-59A0.
-1шт.
|1
114-15-51010
TRANSMISSION ASS'Y
SN: 47617-UP
1шт.
|1
114-15-00511
TRANSMISSION ASS'Y
SN: 45421-47616
1шт.
|1
114-15-00511
TRANSMISSION ASS'Y,(FOR TWO LEVERS STEERING)
SN: 45421-UP
1шт.
|1
0
TRANSMISSION ASS'Y
SN: 45001-45420
1шт.
|$$11
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO F2320-55A0 AND F2320-57A0 TO F2320-59A0.
-1шт.
|1
113-15-00483
VALVE ASS'Y,MODULATION
SN: 45421-UP
1шт.
|1
0
VALVE ASS'Y,MODULATION
SN: 45001-45420
1шт.
1
104-15-25110
BODY
SN: 45001-UP
1шт.
2
104-15-25210
SPOOL
SN: 45001-UP
1шт.
3
104-15-25290
SPRING¤ (L= 62.0)
SN: 45001-UP
1шт.
4
113-15-45280
SPRING
SN: 45001-UP
1шт.
5
113-15-35220
VALVE
SN: 45001-UP
1шт.
7
113-15-25270
SHIM¤ 0.2MM
SN: 45001-UP
2шт.
8
104-15-25260
SPACER
SN: 45001-UP
1шт.
12
104-15-25323
SPOOL
SN: (2997)-UP
1шт.
|12
104-15-25322
SPOOL
SN: 45421-(2996)
1шт.
|12
0
SPOOL
SN: 45001-45420
1шт.
13A
124-15-55390
STOPPER
SN: (2997)-UP
1шт.
15
104-15-25340
STOPPER
SN: 45001-UP
2шт.
17
103-15-25350
PLATE
SN: 45001-UP
2шт.
19
01010-80860
BOLT
SN: 45001-UP
3шт.
|21
113-15-00491
SEAT ASS'Y
SN: 45001-UP
1шт.
21
0
SEAT
SN: 45001-UP
1шт.
23
104-15-25140
GASKET (K2)
SN: 45001-UP
1шт.
Выбрано товаров: 48
