Запчасти Komatsu 4D105-5H ГОЛОВКА ЦИЛИНДРОВ ГОЛОВКА ЦИЛИНДРОВ
№
Артикул
Название
Примечание
Количество
|$0
6134-12-1020
CYLINDER HEAD ASS'Y,WITH VALVE
SN: 150001-UP
1шт.
|$1
6134-11-1011
CYLINDER HEAD ASS'Y,WITH VALVE
SN: 106581-149999
1шт.
|$2
6134-12-1300
CYLINDER HEAD ASS'Y,VALVE LESS
SN: 150001-UP
1шт.
|$3
6134-11-1101
CYLINDER HEAD ASS'Y,VALVE LESS
SN: 106581-149999
1шт.
1
0
HEAD,CYLINDER
SN: 150001-UP
1шт.
1
0
HEAD,CYLINDER
SN: 106581-149999
1шт.
3
6136-11-1310
SEAT,INTAKE VALVE (STD)
SN: 106581-149999
4шт.
3
6136-19-1410
SEAT, 0.25MM,INTAKE VALVE (OS)
SN: 150001-UP
4шт.
3
6134-19-1310
SEAT, 0.25MM,INTAKE VALVE (OS)
SN: 106581-149999
4шт.
3
6136-18-1410
SEAT, 0.50MM,INTAKE VALVE (OS)
SN: 150001-UP
4шт.
3
6134-18-1310
SEAT, 0.50MM,INTAKE VALVE (OS)
SN: 106581-149999
4шт.
3
6136-17-1410
SEAT, 0.75MM,INTAKE VALVE (OS)
SN: 150001-UP
4шт.
3
6134-17-1310
SEAT, 0.75MM,INTAKE VALVE (OS)
SN: 106581-149999
4шт.
3
6136-16-1410
SEAT, 1.00MM,INTAKE VALVE (OS)
SN: 150001-UP
4шт.
3
6134-16-1310
SEAT, 1.00MM,INTAKE VALVE (OS)
SN: 106581-149999
4шт.
4
6134-11-1320
SEAT,EXHAUST VALVE (STD)
SN: 106581-149999
4шт.
4
6136-19-1420
SEAT, 0.25MM,EXHAUST VALVE (OS)
SN: 150001-UP
4шт.
4
6134-19-1320
SEAT, 0.25MM,EXHAUST VALVE (OS)
SN: 106581-149999
4шт.
4
6136-18-1420
SEAT, 0.50MM,EXHAUST VALVE (OS)
SN: 150001-UP
4шт.
4
6134-18-1320
SEAT, 0.50MM,EXHAUST VALVE (OS)
SN: 106581-149999
4шт.
4
6136-17-1420
SEAT, 0.75MM,EXHAUST VALVE (OS)
SN: 150001-UP
4шт.
4
6134-17-1320
SEAT, 0.75MM,EXHAUST VALVE (OS)
SN: 106581-149999
4шт.
4
6136-16-1420
SEAT, 1.00MM,EXHAUST VALVE (OS)
SN: 150001-UP
4шт.
4
6134-16-1320
SEAT, 1.00MM,EXHAUST VALVE (OS)
SN: 106581-149999
4шт.
5
6136-19-1330
GUIDE,VALVE
SN: 106581-149999
8шт.
11
6136-41-4410
SPRING,VALVE
SN: 106581-149999
8шт.
12
6136-41-4510
GUIDE,SPRING
SN: 106581-149999
8шт.
15
6134-11-1812
GASKET,HEAD (K1)
SN: 167198-UP
1шт.
15
0
GASKET,HEAD (K1)
SN: 106581-167197
1шт.
16
6136-11-1610
BOLT,HEAD
SN: 106581-149999
18шт.
17
6138-11-1621
WASHER
SN: 107305-149999
18шт.
17
0
WASHER
SN: 106581-107304
18шт.
18
6136-11-1910
HANGER,FRONT
SN: 106581-UP
1шт.
19
6136-11-1821
GASKET (K1)
SN: 106581-UP
1шт.
20
6134-11-1930
HANGER,REAR
SN: 106581-UP
1шт.
|$0
6134-12-1020
CYLINDER HEAD ASS'Y,WITH VALVE
SN: 150001-UP
1шт.
|$1
6134-11-1011
CYLINDER HEAD ASS'Y,WITH VALVE
SN: 106581-149999
1шт.
|$2
6134-12-1300
CYLINDER HEAD ASS'Y,VALVE LESS
SN: 150001-UP
1шт.
|$3
6134-11-1101
CYLINDER HEAD ASS'Y,VALVE LESS
SN: 106581-149999
1шт.
1
0
HEAD,CYLINDER
SN: 150001-UP
1шт.
1
0
HEAD,CYLINDER
SN: 106581-149999
1шт.
3
6136-11-1310
SEAT,INTAKE VALVE (STD)
SN: 106581-149999
4шт.
3
6136-19-1410
SEAT, 0.25MM,INTAKE VALVE (OS)
SN: 150001-UP
4шт.
3
6134-19-1310
SEAT, 0.25MM,INTAKE VALVE (OS)
SN: 106581-149999
4шт.
3
6136-18-1410
SEAT, 0.50MM,INTAKE VALVE (OS)
SN: 150001-UP
4шт.
3
6134-18-1310
SEAT, 0.50MM,INTAKE VALVE (OS)
SN: 106581-149999
4шт.
3
6136-17-1410
SEAT, 0.75MM,INTAKE VALVE (OS)
SN: 150001-UP
4шт.
3
6134-17-1310
SEAT, 0.75MM,INTAKE VALVE (OS)
SN: 106581-149999
4шт.
3
6136-16-1410
SEAT, 1.00MM,INTAKE VALVE (OS)
SN: 150001-UP
4шт.
3
6134-16-1310
SEAT, 1.00MM,INTAKE VALVE (OS)
SN: 106581-149999
4шт.
4
6134-11-1320
SEAT,EXHAUST VALVE (STD)
SN: 106581-149999
4шт.
4
6136-19-1420
SEAT, 0.25MM,EXHAUST VALVE (OS)
SN: 150001-UP
4шт.
4
6134-19-1320
SEAT, 0.25MM,EXHAUST VALVE (OS)
SN: 106581-149999
4шт.
4
6136-18-1420
SEAT, 0.50MM,EXHAUST VALVE (OS)
SN: 150001-UP
4шт.
4
6134-18-1320
SEAT, 0.50MM,EXHAUST VALVE (OS)
SN: 106581-149999
4шт.
4
6136-17-1420
SEAT, 0.75MM,EXHAUST VALVE (OS)
SN: 150001-UP
4шт.
4
6134-17-1320
SEAT, 0.75MM,EXHAUST VALVE (OS)
SN: 106581-149999
4шт.
4
6136-16-1420
SEAT, 1.00MM,EXHAUST VALVE (OS)
SN: 150001-UP
4шт.
4
6134-16-1320
SEAT, 1.00MM,EXHAUST VALVE (OS)
SN: 106581-149999
4шт.
5
6136-19-1330
GUIDE,VALVE
SN: 106581-149999
8шт.
11
6136-41-4410
SPRING,VALVE
SN: 106581-149999
8шт.
12
6136-41-4510
GUIDE,SPRING
SN: 106581-149999
8шт.
15
6134-11-1812
GASKET,HEAD (K1)
SN: 167198-UP
1шт.
15
0
GASKET,HEAD (K1)
SN: 106581-167197
1шт.
16
6136-11-1610
BOLT,HEAD
SN: 106581-149999
18шт.
17
6138-11-1621
WASHER
SN: 107305-149999
18шт.
17
0
WASHER
SN: 106581-107304
18шт.
18
6136-11-1910
HANGER,FRONT
SN: 106581-UP
1шт.
19
6136-11-1821
GASKET (K1)
SN: 106581-UP
1шт.
20
6134-11-1930
HANGER,REAR
SN: 106581-UP
1шт.
