Артикул
Название
Примечание
Количество
|1
104-15-32090
TRANSMISSION ASS'Y,(FOR 2 LEVER STEERING)
SN: 63001-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO 59A0¤ 60A3¤ AND 61A2 TO 63A2.
-1шт.
|1
104-15-41010
TRANSMISSION ASS'Y,(FOR MONO LEVER STEERING)
SN: 63001-UP
1шт.
|$$4
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-51A2 TO F2320-63A2.
-1шт.
|1
103-15-00511
VALVE ASS'Y
SN: 63001-UP
1шт.
|1
103-15-00531
SEAT ASS'Y
SN: 63001-UP
1шт.
1
0
SEAT
SN: 63001-UP
1шт.
3
104-15-25110
BODY
SN: 63001-UP
1шт.
4
104-15-25140
GASKET (K2)
SN: 63001-UP
1шт.
5
01010-80860
BOLT
SN: 63001-UP
3шт.
11
103-15-25350
PLATE
SN: 63001-UP
2шт.
14
104-15-25322
SPOOL
SN: 63001-UP
1шт.
15
104-15-25220
VALVE
SN: 63001-UP
1шт.
16
104-15-25280
SPRING
SN: 63001-UP
1шт.
17
104-15-25290
SPRING¤ (L= 62.0)
SN: 63001-UP
1шт.
18
104-15-25210
SPOOL
SN: 63001-UP
1шт.
|22
113-15-25270
SHIM¤ 0.2MM (K2)
SN: 63001-UP
2шт.
24
104-15-25260
SPACER
SN: 63001-UP
1шт.
25
104-15-25340
STOPPER
SN: 63001-UP
2шт.
31
113-15-21770
SLEEVE
SN: 63001-UP
1шт.
Выбрано товаров: 41
