Запчасти Doosan Daewoo SWING REDUCTION GEAR SWING DEVICE ASSY

-

K1004160A

GEAR;REDUCTION

SERIAL: 1193

1шт.

1

2423-1496G

CASING

desc: CARTER

1шт.

2

2112-1248E

SHAFT;DRIVE

desc: AXE

1шт.

3

2412-1040

PLATE

desc: RONDELLE

1шт.

4

2109-9033

BEARING;ROLLER

desc: ROULEMENT A BILLES

1шт.

5

2891-1421B

PLATE;COVER

desc: PLAQUE

1шт.

6

S6500380

RING;SNAP

desc: PLAQUE

3шт.

7

2180-1254

SEAL;OIL

desc: JOINT D'HUILE

1шт.

8

109-00174

BEARING;ROLLER

desc: ROULEMENT A BILLES

1шт.

9

104-00051A

GEAR;RING

desc: PIGNON

1шт.

10

230-00061

CARRIER NO.2

desc: SUPPORT

1шт.

11

2114-1901A

WASHER;THRUST NO.2

desc: RONDELLE

4шт.

12

104-00050

GEAR;PLANET NO.2

desc: PIGNON

4шт.

13

110-00219

BUSH NO.2

desc: MANCHON

4шт.

14

123-00437A

PIN NO.2

desc: GOUJON

4шт.

15

S5741341

PIN;SPRING

desc: GOUPILLE FENDUE

4шт.

16

S0121061

BOLT M16X25

desc: BOULONE A 6 PANS

1шт.

17

114-00548

WASHER;THRUST NO.3

desc: RONDELLE

1шт.

18

104-00048

GEAR;SUN NO.2

desc: PIGNON

1шт.

19

2705-1030

PIN;KNOCK

desc: BROCHE DE BLOCAGE

4шт.

20

230-00060A

CARRIER NO.1

desc: SUPPORT

1шт.

21

114-00527

WASHER;THRUST NO.1

desc: RONDELLE

3шт.

22

104-00049A

GEAR;PLANET NO.1

desc: PIGNON

3шт.

23

123-00435A

PIN ASS'Y NO.1

desc: GOUJON

3шт.

24

S2217471

BOLT;SOCKET M12X150

desc: BOULON DE PLOT

16шт.

25

104-00047A

GEAR;SUN NO.1

desc: PIGNON

1шт.

26

S6500450

RING;SNAP

desc: BAGUE D'ARRET

1шт.

27

2181-1116D2

PLUG PT1/4

desc: BOUCHON

2шт.

28

2181-1116D4

PLUG PT1/2

desc: BOUCHON

1шт.

29

2140-1406

PIPE;LEVEL GAUGE

desc: TUYAU

1шт.

30

2119-1065

LEVEL GAUGE

desc: JAUGE DE NIVEAU

1шт.

31

S5231090

WASHER;DOUBLE TAP

desc: RONDELLE

1шт.

32

140-01374A

PIPE

desc: TUYAU

4шт.

33

120-00144

BOLT;HEX. M10X1.5X25

desc: BOULON A 6 PANS

8шт.
