Запчасти Doosan Daewoo SWING DEVICE ASSY BODY PARTS

-

401-00374

SWING DEVICE ASS'Y

SERIAL: 1001-1215

-2шт.

-

401-00374A

SWING DEVICE ASS'Y

SERIAL: 1216

-2шт.

1

401-00375

SWING DEVICE SUB ASS'Y

SERIAL: 1001-1103

1шт.

1

401-00375A

SWING DEVICE SUB ASS'Y

SERIAL: 1104-1192

1шт.

1

401-00375B

SWING DEVICE SUB ASS'Y

SERIAL: 1193-1215

1шт.

1

401-00375C

SWING DEVICE SUB ASS'Y

SERIAL: 1216

1шт.

1A

401-00290

SWING DEVICE SUB ASS'Y

SERIAL: 1001-1103

1шт.

1A

401-00405

SWING DEVICE SUB ASS'Y

SERIAL: 1104-1215

1шт.

1A

401-00405B

SWING DEVICE SUB ASS'Y

SERIAL: 1216

1шт.

1AA

401-00086A

MOTOR;SWING

SERIAL: 1001-1215

1шт.

1AA

401-00086B

MOTOR;SWING

SERIAL: 1216

1шт.

1AB

2404-1063I

REDUCTION GEAR ASS'Y

SERIAL: 1001-1103

1шт.

1AB

2404-1063J

REDUCTION GEAR ASS'Y

SERIAL: 1104-1192

1шт.

1AB

K1004160A

REDUCTION GEAR ASS'Y

SERIAL: 1193

1шт.

1B

2182-1662

PIPE

desc: . TUYAU

1шт.

1C

2119-1063A

CAP

desc: . CHAPEAU

1шт.

1D

2181-1913D24

REDUCER

desc: . REDUCEUR

1шт.

1E

2181-1110D3

ADAPTER

desc: . ADAPTATEUR

1шт.

1F

2184-1096D91

HOSE PF1/2-850L

desc: . TUYAU FLEXIBLE

1шт.

1G

121-00010D3

NUT

desc: . ECROU

1шт.

1H

181-00698

REDUCER

desc: . REDUCEUR

1шт.

1I

2181-1950D3

PLUG

desc: . BOUCHON

1шт.

1J

S8000181

O-RING

desc: . JOINT TORIQUE

1шт.

1K

S5011113

WASHER;PLAIN

desc: . RONDELLE PLATE

1шт.

2

2123-4030

PIN;LOCK

desc: GOUJON

1шт.

3

2114-9012A

WASHER;HARD

desc: RONDELLE

11шт.

4

S0570166

BOLT M20X2.5X65

desc: BOULON A 6 PANS

11шт.

5

160-00027

CAP

desc: CHAPEAU

2шт.
