Запчасти Doosan Daewoo PILOT PIPING-TWO LEVER+2 SPOOL BODY PARTS

-

4400-2079F2

PILOT PIPING-TWO LEVER + 2 SPOOL

SC: D

-2шт.

5

S8180221

RING;SEAL

desc: RONDELLE D'ETANCHEITE

10шт.

8

4197-2473A

BRACKET

desc: SUPPORT

1шт.

9

S0512053

BOLT M10X1.5X25

desc: BOULON A 6 PANS

4шт.

10

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

10шт.

12

2181-2718

ADAPTER PF3/8-PF3/8

desc: RACCORD ADAPTATEUR

8шт.

13

2184-1036D256

HOSE PF3/8-650L

desc: TUYAU FLEXIBLE

2шт.

14

2184-1036D2

HOSE PF3/8-600L

desc: TUYAU FLEXIBLE

3шт.

15

2181-1702D3

ELBOW;S PF1/4-PF3/8

desc: RACCORD

2шт.

16

2181-1126D85

ADAPTER;S PF1/4-PF3/8

desc: RACCORD

2шт.

17

S8000111

O-RING P11

desc: JOINT TORIQUE

5шт.

19

2184-1026D66

HOSE PF3/8-600L

desc: TUYAU FLEXIBLE

1шт.

20

2184-1036D114

HOSE PF3/8-960L

desc: TUYAU FLEXIBLE

1шт.

21

2184-1026D163

HOSE PF3/8-950L

desc: TUYAU FLEXIBLE

1шт.

22

4420-9581

VALVE;PILOT

desc: VANNE PILOTE

1шт.

23

4197-2686A

BRACKET

desc: SUPPORT

1шт.

24

S0511853

BOLT M10X1.5X20

desc: BOULON A 6 PANS

6шт.

26

S8000181

O-RING P18

desc: JOINT TORIQUE

6шт.

27

2460-9057

ACCUMULATOR;PILOT

desc: RESERVOIR

1шт.

28

4474-9061

FILTER;IN LINE

desc: FILTRE

1шт.

28A

00179

O-RING

desc: . JOINT TORIQUE

1шт.

28B

00552

RING;BACK UP

desc: . ANNEAU DE SOUTIEN

1шт.

29

4197-2512

BRACKET

desc: SUPPORT

1шт.

30

2181-1702D5

ELBOW PF3/8-PF3/8

desc: COUDE EN S

1шт.

31

S8000141

O-RING P14

desc: JOINT TORIQUE

2шт.

32

2181-1702D9

ELBOW;90ЎЖ PF1/2-PF3/8

desc: COUDE

4шт.

33

2181-1951D31

TEE PF1/2-PF3/8-PF3/8

desc: TE

1шт.

34

2184-1036D27

HOSE PF3/8-2300L

desc: TUYAU FLEXIBLE

1шт.

35

2181-1126D14

ADAPTER PF1/4-PF1/4

desc: RACCORD ADAPTATEUR

1шт.

36

2184-1026D149

HOSE PF3/8-610L

desc: TUYAU FLEXIBLE

1шт.

37

2184-1026D70

HOSE PF3/8-450L

desc: TUYAU FLEXIBLE

1шт.

38

2181-2419D4

ELBOW PF1/2-PF3/8

desc: COUDE

1шт.

39

4420-1239

REMOCON VALVE-TWO LEVER

desc: CONTROLEUR

1шт.

41

S0511751

BOLT M10X1.5X18

desc: BOULON A 6 PANS

4шт.

42

2114-1058D63

WASHER M10

desc: RONDELLE

4шт.

43

2181-1126D49

ADAPTER UNF9/16-PF3/8

desc: RACCORD ADAPTATEUR

1шт.

44

S8040061

O-RING

desc: JOINT TORIQUE

1шт.

45

2181-1126D8

ADAPTER UNF3/4-PF3/8

desc: RACCORD ADAPTATEUR

1шт.

46

S8040081

O-RING

desc: JOINT TORIQUE

1шт.

47

4184-1304

HOSE;BANJO PF3/8-UNF9/16

desc: TUYAU

4шт.

48

4120-2223

BOLT;HOLLOW

desc: BOULON A 6 PANS

2шт.

49

4120-2222

BOLT;HOLLOW

desc: BOULON A 6 PANS

2шт.

50

4114-2009

SPACER;TUBE

desc: BAGUE

2шт.

51

2184-1090D28

HOSE PF3/8-1850L

desc: TUYAU FLEXIBLE

1шт.

52

2184-1090D29

HOSE PF3/8-1700L

desc: TUYAU FLEXIBLE

1шт.

58

S4012533

NUT M8X1.25

desc: ECROU

5шт.

59

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

5шт.

60

2181-1950D2

PLUG PF3/8

desc: BOUCHON

1шт.

66

2124-1353D4

CLIP

desc: ATTACHE

8шт.

67

S0508553

BOLT M8X1.25X14

desc: BOULON A 6 PANS

3шт.

68

2181-1126D23

ADAPTER PF1/2-PF3/8

desc: RACCORD

1шт.

69

2124-1353D18

CLIP

desc: ATTACHE

2шт.

70

S0511653

BOLT M10X1.5X16

desc: BOULON A 6 PANS

2шт.

71

2184-1036D113

HOSE PF3/8-1730L

desc: TUYAU FLEXIBLE

1шт.

72

2184-1026D129

HOSE PF3/8-1350L

desc: TUYAU FLEXIBLE

1шт.
