Запчасти Doosan Daewoo REMOCON VALVE-TWO LEVER PILOT PIPING-TWO LEVER+2 SPOOL

-

4420-1239

REMOCON VALVE-TWO LEVER

desc: CONTROLEUR

1шт.

1

4132-9025

SWITCH;KNOB

desc: BOSSE

1шт.

2

2132-9018

SWITCH;KNOB

desc: INTERUPTEUR

1шт.

3

4112-1256

BAR;HANDLE

desc: LEVIER

1шт.

4

4112-1257

BAR;HANDLE

desc: LEVIER

1шт.

5

S4012733

NUT M12X1.75

desc: ECROU

2шт.

6

4420-9548

REMOCON VALVE;TWO LEVER

desc: CONTROLEUR

1шт.

6-1

43-210

O-RING

desc: . JOINT TORIQUE

1шт.

6-2

43-213

O-RING

desc: . JOINT TORIQUE

1шт.

6-3

51768-1

BOOT

desc: . GAINE DE PROTECTION

2шт.

6-4

51770

RING;RETAINING

desc: . RONDELLE DE RETENUE

4шт.

6-5

51774

PIN;PIVOT

desc: . GOUJON

2шт.

6-6

52206-20

MAGNETIC SHELL

desc: . MAGNETQUE COQUE

3шт.

6-7

53402-A3

PLUNGER ASS'Y

desc: . PLONGEUR

4шт.

6-8

55686

GASKET

desc: . JOINT

2шт.

6-9

55687

GASKET

desc: . JOINT

2шт.

6-10

51614-A6

METERING CAPSULE ASS'Y

desc: . PLUNGEUR

4шт.

6-11

51615-105

PLUNGER CAPSULE ASS'Y

desc: . PLUNGEUR

1шт.

6-12

52735-58

PLUNGER FEEL CAPSULE ASS'Y

desc: . PLUNGEUR

3шт.

6-13

53749

SEAL KIT;METERING CAPSULES

desc: . KIT DE REPARATION

-2шт.

6-14

53817

SEAL KIT;PLUNGER CAPSULES

desc: . KIT DE REPARATION

-2шт.
