Запчасти Doosan Daewoo CONTROL VALVE PIPING-2 SPOOL STD BODY PARTS

-

400-00537

CONTROL VALVE PIPING

SERIAL: 1021

-2шт.

1

4197-2419A

BRACKET

desc: SUPPORT

2шт.

2

2124-1025D2

CLAMP;PIPE

desc: ATTACHE DE TUBE

2шт.

3

4182-1790C

PIPE

desc: CONDUITE

1шт.

4

4182-1789B

PIPE

desc: CONDUITE

1шт.

5

2184-1036D440

HOSE PF3/4-780L

desc: TUYAU FLEXIBLE

1шт.

6

2184-1036D109

HOSE PF3/4-565L

desc: TUYAU FLEXIBLE

1шт.

7

2184-1054D57

HOSE PF1/2-1050L

desc: TUYAU FLEXIBLE

4шт.

8

S2215561

BOLT M12X1.75X45

SERIAL: 1021-1065

3шт.

8

S2215566

BOLT M12X1.75X45

SERIAL: 1066

3шт.

9

2181-1702D78

ELBOW;S UNF1 3/16-PF3/4

desc: RACCORD

1шт.

10

2181-1702D79

ELBOW;L UNF1 3/16-PF3/4

desc: RACCORD

1шт.

11

2181-1126D6

ADAPTER;S PFO1/2-PF1/2

desc: RACCORD ADAPTATEUR

4шт.

12

2181-1126D88

ADAPTER;S PFO1/2-PF3/4

SERIAL: 1021-1068

3шт.

12

2181-1126D88

ADAPTER;S PFO1/2-PF3/4

SERIAL: 1069

4шт.

13

S0558653

BOLT M10X1.5X55

desc: BOULON A 6 PANS

3шт.

14

S4012633

NUT M10X1.5

desc: ECROU

3шт.

15

S5010613

WASHER;PLAIN M10

desc: RONDELLE

10шт.

16

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

9шт.

17

S0511853

BOLT M10X1.5X20

desc: BOULON A 6 PANS

4шт.

18

S8000181

O-RING

desc: JOINT TORIQUE

8шт.

19

S8040141

O-RING

desc: JOINT TORIQUE

4шт.

20

4197-2418A

BRACKET

desc: SUPPORT

1шт.

21

2124-1025D1

CLAMP

desc: ATTACHE DE TUYAU

2шт.

22

4182-1792A

PIPE

desc: CONDUITE

1шт.

23

4182-1791A

PIPE

desc: CONDUITE

1шт.

24

2184-1026D382

HOSE PF3/4-870L

desc: TUYAU FLEXIBLE

2шт.

25

2181-1126D140

ADAPTER;S UN1 3/16-PF3/4

desc: RACCORD

1шт.

26

2181-1126D141

ADAPTER;S UN1 3/16-PF3/4

desc: RACCORD ADAPTATEUR

1шт.

27

S0512053

BOLT M10X1.5X25

desc: BOULON A 6 PANS

2шт.

28

S5110701

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

3шт.

29

420-00144

VALVE;CONTROL 2-SPOOL

desc: TIROIRS DE COMMANDE

1шт.

31

2181-1126D135

ADAPTER PF1/2-PF3/4

SERIAL: 1021-1068

1шт.
