Запчасти Doosan Daewoo CONTROL VALVE(2-SPOOL) CONTROL VALVE PIPING-2 SPOOL STD

-

420-00144

CONTROL VALVE(2-SPOOL)

SERIAL: 1021

1шт.

1

6001-D111

INLET SECTION

desc: BLOC

1шт.

2

6002-V76

WORK SECTION-OPTION

desc: BLOC

1шт.

4

6002-K174

WORK SECTION-BOOM

desc: BLOC

1шт.

5

6003-E1

OUTLET SECTION

desc: BLOC

1шт.

6

6246-43

TIE ROD

desc: TIGE

3шт.

7

51055-20

MAIN RELIEF VALVE

desc: ENSEMBLE CLAPET DE RECHARGE

1шт.

8

51799-12

O-RING

desc: JOINT TORIQUE

1шт.

9

51650-4

OVER LOAD RELIEF VALVE

desc: ENSEMBLE CLAPET DE DECHARGE

2шт.

10

55321

O-RING

desc: JOINT TORIQUE

4шт.

11

5375-F

ANTI CAVITATION VALVE

desc: ENSEMBLE CLAPET DE DECHARGE

1шт.

12

52587

O-RING

desc: JOINT TORIQUE

1шт.

13

11270

PLUG

desc: BOUCHONE

1шт.

*

59669

SEAL KIT;CONTROL VALVE

desc: KIT DE REPARATION

1шт.

14

-

O-RING

SC: D

4шт.

15

-

O-RING

SC: D

3шт.

16

-

O-RING

SC: D

3шт.

17

-

RING;BACK UP

SC: D

1шт.
