Запчасти Case IH 184 (A-23) - RIGID ROCKSHAFT WITH LIFT LINK, FOR FARMALL SUPER A, 100, 130 & 140 TRACTORS

Схема запчастей Case IH 184 - (A-23) - RIGID ROCKSHAFT WITH LIFT LINK, FOR FARMALL SUPER A, 100, 130 & 140 TRACTORS
1
7
1
6
2
5
4
4
3
2
3

Артикул

Название

Примечание

Количество

1

515226R91

ROCKSHAFT

LINK ASSEMBLY, lifting, consists of (1) link 515059R1, (1) swivel 515060R91

1шт.

2

515059R1

ROD

LINK, lifting

1шт.

NUT, 3/4 jam

1шт.

3

515060R91

END

SWIVEL, lifting link

1шт.

4

PO18499

COTTER PIN

quick attachable cotter

1шт.

WASHER, 21/32 x 1-/4 x 16 ga

1шт.

5

109358

FITTING, 5/16 drive type straight lub.

1шт.

6

512447R21

BEARING ASSY

W/FITTING, rockshaft

1шт.

BOLT W/NUT, 3/8 x 1 crg

3шт.

WASHER, 3/8 lock

3шт.

WASHER, 13/32 x 1 x 16 ga

3шт.

7

512453R93

ROCKSHAFT

1шт.

1431BX

COLLAR CLAMP

COLLAR W/SET SCREW, lifting link

1шт.

1

516192R1

ROD

LINK, lifting rockshaft straight

1шт.

PIN, 3/16 x 1-1/4 cotter

2шт.

2

514553R93

ROCKSHAFT, lifting

1шт.

PIN, 1/4 x 2 cot

1шт.

WASHER, 1-17/32 x 2-1/4 x 1 ga

1шт.

3

515741R1

BRACKET, mounting rockshaft

1шт.

SCREW, 1/2 x 1-1/2 cap

3шт.

WASHER, 1/2 lock

3шт.

4

514548R1

CAP

BEARING, lifting rockshaft lower half

1шт.

4

514549R1

CAP

BEARING, lifting rockshaft upper half

1шт.

Выбрано товаров: 23
