Запчасти Komatsu FB14-18RS-12 РАМА (С ХОЛОДН.) РАМА

1

0

FRAME ASS'Y,(FOR 1.0 TON)

SN: 85001-UP

1шт.

|$7

0

FRAME ASS'Y,(FOR 1.3 TON)

SN: 85001-UP

1шт.

|$8

0

FRAME ASS'Y,(FOR 1.5 TON)

SN: 85001-UP

1шт.

|$9

0

FRAME ASS'Y,(FOR 1.5 TON) (COLD)

SN: 85001-UP

1шт.

|$10

0

FRAME ASS'Y,(FOR 1.8 TON)

SN: 85001-UP

1шт.

|$11

0

FRAME ASS'Y,(FOR 1.8 TON) (COLD)

SN: 85001-UP

1шт.

2

37R-BLC-1101

RAIL,(FOR 1.0 TON)

SN: 85001-UP

2шт.

|$13

37R-BLC-1131

RAIL,(FOR 1.3 TON)

SN: 85001-UP

2шт.

|$14

37R-BLC-1151

RAIL,(FOR 1.5 TON)

SN: 85001-UP

2шт.

|$15

37R-BLC-1181

RAIL,(FOR 1.8 TON)

SN: 85001-UP

2шт.

3

3LA-50-17214YL

DOOR,(FOR 1.0 TON TO 1.8 TON)

SN: 85001-UP

1шт.

|$17

3LA-50-17214WL

DOOR,(FOR 1.5TON AND 1.8TON) (COLD)

SN: 85001-UP

1шт.

4

3MA-77-12280

BUSHING

SN: 85001-UP

2шт.

5

3LA-50-17391

LOCK

SN: 85001-UP

1шт.

6

01010-81035

BOLT

SN: 85001-UP

2шт.

7

01602-21030

WASHER,SPRING

SN: 85001-UP

2шт.

8

01643-31032

WASHER

SN: 85001-UP

2шт.

9

01580-11008

NUT

SN: 85001-UP

2шт.

10

3LA-50-17273

BRACKET

SN: 85001-UP

1шт.

11

01010-80830

BOLT

SN: 85001-UP

2шт.

12

01643-30823

WASHER

SN: 85001-UP

2шт.

13

3LA-50-17263

LEVER

SN: 85001-UP

1шт.

14

01580-10403

NUT

SN: 85001-UP

2шт.

15

37B-2BX-0610

SCREW,STAINLESS

SN: 85001-UP

1шт.

16

37B-2BX-3060

WASHER,STAINLESS

SN: 85001-UP

1шт.

17

3LA-50-17382

PIN

SN: 85001-UP

1шт.

18

01643-31032

WASHER

SN: 85001-UP

1шт.

19

3LA-50-17371

BRACKET

SN: 85001-UP

1шт.

20

3BA-50-51270

COVER

SN: 85001-UP

2шт.

21

3RA-50-76555

SPONGE

SN: 85001-UP

1шт.

22

3RA-44-61841

PIN

SN: 85001-UP

1шт.

23

07020-00000

FITTING,GREASE

SN: 85001-UP

1шт.

24

01010-80820

BOLT

SN: 85001-UP

1шт.

25

01602-20825

WASHER,SPRING

SN: 85001-UP

1шт.

26

01010-81020

BOLT

SN: 85001-UP

2шт.

27

01580-11008

NUT

SN: 85001-UP

2шт.

28

01010-80616

BOLT

SN: 85001-UP

1шт.

29

01594-00606

NUT

SN: 85001-UP

1шт.

30

3EB-50-31130

CUSHION,(FOR 1.5 TON AND 1.8 TON)

SN: 85001-UP

1шт.
