Запчасти Komatsu FB15RL-14 REACH ЦИЛИНДР (ДЛЯ TFV МАЧТА) (ВНУТР. ЧАСТИ) (С ХОЛОДН.) ГИДРАВЛИКА

|$12

37R-550-8290UE

CYLINDER ASS'Y,(FOR FB10RL)

SN: 140001-UP

1шт.

|$13

37R-550-8300UE

CYLINDER ASS'Y,(FOR FB13RL)

SN: 140001-UP

1шт.

|$14

37R-550-8330UE

CYLINDER ASS'Y,(FOR FB14RL) (LARGE CAPACITY)

SN: 140001-UP

1шт.

|$15

37R-550-8310UE

CYLINDER ASS'Y,(FOR FB15RL) (LARGE CAPACITY)

SN: 140001-UP

1шт.

|$16

37R-550-8320UE

CYLINDER ASS'Y,(FOR FB18RL) (LARGE CAPACITY)

SN: 140001-UP

1шт.

|$17

37R-550-8260UE

CYLINDER ASS'Y,(FOR FB18RL)

SN: 140001-UP

1шт.

|$18

37R-550-8290UT

CYLINDER ASS'Y,(FOR FB10RL) (COLD)

SN: 140001-UP

1шт.

|$19

37R-550-8300UT

CYLINDER ASS'Y,(FOR FB13RL) (COLD)

SN: 140001-UP

1шт.

|$20

37R-550-8330UT

CYLINDER ASS'Y,(14RL) (COLD) (LARGE CAPACITY)

SN: 140001-UP

1шт.

|$21

37R-550-8310UT

CYLINDER ASS'Y,(15RL) (COLD) (LARGE CAPACITY)

SN: 140001-UP

1шт.

|$22

37R-550-8320UT

CYLINDER ASS'Y,(18RL) (COLD) (LARGE CAPACITY)

SN: 140001-UP

1шт.

|$23

37R-550-8260UT

CYLINDER ASS'Y,(FOR FB18RL) (COLD)

SN: 140001-UP

1шт.

1

3LA-64-37080

TUBE,10/13RL,14/15RL LARGE CAPACITY

SN: 140001-UP

1шт.

|$25

3LA-64-37070

TUBE,(18RL)(LARGE CAPACITY),(18RL)

SN: 140001-UP

1шт.

2

3LA-64-38140

ROD,(FOR FB10RL, 13RL)

SN: 140001-UP

1шт.

|$27

3LA-64-38120

ROD,(FOR 14-18RL) (LARGE CAPACITY)

SN: 140001-UP

1шт.

|$28

3LA-64-38200

ROD,(FOR FB18RL)

SN: 140001-UP

1шт.

3

30R-64-11160

PISTON,10/13RL,14-18RL LARGE CAPACITY

SN: 140001-UP

1шт.

|$30

30R-64-11170

PISTON,(FOR FB18RL)

SN: 140001-UP

1шт.

4

30R-64-11110

NUT,SELFLOCK

SN: 140001-UP

1шт.

5

07000-13044

O-RING

SN: 140001-UP

2шт.

6

30R-64-11120

RING,BACK-UP

SN: 140001-UP

2шт.

7

30R-64-11130

GUIDE

SN: 140001-UP

1шт.

8

30R-64-11140

DUST SEAL

SN: 140001-UP

1шт.

9

07000-12050

O-RING

SN: 140001-UP

1шт.

10

07177-03020

BUSHING

SN: 140001-UP

1шт.

11

3EB-64-13270

U-PACKING

SN: 140001-UP

1шт.

12

3LA-64-38720

SPACER,(FOR FB10RL)

SN: 140001-UP

1шт.

|$40

3LA-64-38660

SPACER,(FOR FB13RL)

SN: 140001-UP

1шт.

|$41

3LA-64-38680

SPACER,(FOR FB14RL) (LARGE CAPACITY)

SN: 140001-UP

1шт.

|$42

3LA-64-38710

SPACER,(FOR FB15RL) (LARGE CAPACITY)

SN: 140001-UP

1шт.

|$43

3LA-64-38780

SPACER,(FOR FB18RL) (LARGE CAPACITY)

SN: 140001-UP

1шт.

13

30R-64-11150

SPACER

SN: 140001-UP

1шт.

14

07000-12030

O-RING

SN: 140001-UP

1шт.

|$$35

SERVICE KIT

-1шт.

KIT

30R-64-05010

SEAL KIT

SN: 140001-UP

1шт.
