Запчасти Komatsu FB15 УПРАВЛЯЮЩ. КЛАПАН (ВНУТР. ЧАСТИ) ГИДРАВЛИКА

|$7

3BA-61-51211

CONTROL VALVE ASS'Y,(FOR 2CV)

SN: 802377-UP

1шт.

|$8

3BA-61-51210

CONTROL VALVE ASS'Y,(FOR 2CV)

SN: 800001-802376

1шт.

|$9

3BA-61-51311

CONTROL VALVE ASS'Y,(FOR 3CV)

SN: 802377-UP

1шт.

|$10

3BA-61-51310

CONTROL VALVE ASS'Y,(FOR 3CV)

SN: 800001-802376

1шт.

|$11

3BA-61-51411

CONTROL VALVE ASS'Y,(FOR 4CV)

SN: 802377-UP

1шт.

|$12

3BA-61-51410

CONTROL VALVE ASS'Y,(FOR 4CV)

SN: 800001-802376

1шт.

|$13

3BA-61-51511

CONTROL VALVE ASS'Y,(FOR 5CV)

SN: 802377-UP

1шт.

|$14

3BA-61-51510

CONTROL VALVE ASS'Y,(FOR 5CV)

SN: 800001-802376

1шт.

|$15

3BA-61-51611

CONTROL VALVE ASS'Y,FOR 3CV WITH PORT RELEF VALVE

SN: 802377-UP

1шт.

|$16

3BA-61-51610

CONTROL VALVE ASS'Y,FOR 3CV WITH PORT RELEF VALVE

SN: 800001-802376

1шт.

|$17

3BA-61-51711

CONTROL VALVE ASS'Y,F0R 4CV WITH PORT RELEF VALVE

SN: 802377-UP

1шт.

|$18

3BA-61-51710

CONTROL VALVE ASS'Y,F0R 4CV WITH PORT RELEF VALVE

SN: 800001-802376

1шт.

|$19

3BA-61-51811

CONTROL VALVE ASS'Y,FOR 5CV WITH PORT RELEF VALVE

SN: 802377-UP

1шт.

|$20

3BA-61-51810

CONTROL VALVE ASS'Y,FOR 5CV WITH PORT RELEF VALVE

SN: 800001-802376

1шт.

1

KHOBP14

PLUG

SN: 800001-UP

8шт.

|$22

KHV981263781

RELEF VALVE ASS'Y,FOR 3CV WITH PORT RELEF VALVE

SN: 800001-UP

2шт.

|$23

KHV981263781

RELEF VALVE ASS'Y,F0R 4CV WITH PORT RELEF VALVE

SN: 800001-UP

6шт.

|$24

KHV981263781

RELEF VALVE ASS'Y,FOR 5CV WITH PORT RELEF VALVE

SN: 800001-UP

8шт.

2

KHPBP116U-2403

PLUG

SN: 800001-UP

8шт.

3

KHOROH14

PLUG

SN: 800001-UP

1шт.

4

KHOORBBP11

O-RING

SN: 800001-UP

8шт.

5

KHV233140-0457

COVER,(FOR 2CV)

SN: 800001-UP

4шт.

|$29

KHV233140-0457

COVER,(FOR 3CV)

SN: 800001-UP

6шт.

|$30

KHV233140-0457

COVER,(FOR 4CV)

SN: 800001-UP

8шт.

|$31

KHV233140-0457

COVER,(FOR 5CV)

SN: 800001-UP

10шт.

6

KHV233140-0357

COVER,(FOR 2CV)

SN: 800001-UP

4шт.

|$33

KHV233140-0357

COVER,(FOR 3CV)

SN: 800001-UP

6шт.

|$34

KHV233140-0357

COVER,(FOR 4CV)

SN: 800001-UP

8шт.

|$35

KHV233140-0357

COVER,(FOR 5CV)

SN: 800001-UP

10шт.

7

KHV0101298683

VALVE

SN: 802377-UP

1шт.

|$37

KHV9903014361

VALVE

SN: 800001-802376

1шт.

8

KHOSSS1M66

SCREW,(FOR 2CV)

SN: 800001-UP

4шт.

|$39

KHOSSS1M66

SCREW,(FOR 3CV)

SN: 800001-UP

6шт.

|$40

KHOSSS1M66

SCREW,(FOR 4CV)

SN: 800001-UP

8шт.

|$41

KHOSSS1M66

SCREW,(FOR 5CV)

SN: 800001-UP

10шт.

9

KHODW532

BALL,(FOR 2CV)

SN: 800001-UP

4шт.

|$43

KHODW532

BALL,(FOR 3CV)

SN: 800001-UP

6шт.

|$44

KHODW532

BALL,(FOR 4CV)

SN: 800001-UP

8шт.

|$45

KHODW532

BALL,(FOR 5CV)

SN: 800001-UP

10шт.

10

KH250102761S28

O-RING,(FOR 2CV)

SN: 800001-UP

4шт.

|$47

KH250102761S28

O-RING,(FOR 3CV)

SN: 800001-UP

6шт.

|$48

KH250102761S28

O-RING,(FOR 4CV)

SN: 800001-UP

8шт.

|$49

KH250102761S28

O-RING,(FOR 5CV)

SN: 800001-UP

10шт.

11

KHOSBM516

BOLT,(FOR 2CV)

SN: 800001-UP

8шт.

|$51

KHOSBM516

BOLT,(FOR 3CV)

SN: 800001-UP

12шт.

|$52

KHOSBM516

BOLT,(FOR 4CV)

SN: 800001-UP

16шт.

|$53

KHOSBM516

BOLT,(FOR 5CV)

SN: 800001-UP

20шт.

12

KHOSBM58

BOLT,(FOR 2CV)

SN: 800001-UP

8шт.

|$55

KHOSBM58

BOLT,(FOR 3CV)

SN: 800001-UP

12шт.

|$56

KHOSBM58

BOLT,(FOR 4CV)

SN: 800001-UP

16шт.

|$57

KHOSBM58

BOLT,(FOR 5CV)

SN: 800001-UP

20шт.

13

KHVZ250107146

PLUG,(FOR 2CV)

SN: 800001-UP

2шт.

|$59

KHVZ250107146

PLUG,(FOR 3CV)

SN: 800001-UP

3шт.

|$60

KHVZ250107146

PLUG,(FOR 4CV)

SN: 800001-UP

4шт.

|$61

KHVZ250107146

PLUG,(FOR 5CV)

SN: 800001-UP

5шт.

14

KHVZ5014401

SPRING,(FOR 2CV)

SN: 800001-UP

2шт.

|$63

KHVZ5014401

SPRING,(FOR 3CV)

SN: 800001-UP

3шт.

|$64

KHVZ5014401

SPRING,(FOR 4CV)

SN: 800001-UP

4шт.

|$65

KHVZ5014401

SPRING,(FOR 5CV)

SN: 800001-UP

5шт.

15

KH203340-1258

SPRING

SN: 800001-UP

1шт.

16

KH203340-1257

SPRING

SN: 800001-UP

1шт.

17

KH50107145

PLUG,(FOR 2CV)

SN: 800001-UP

2шт.

|$69

KH50107145

PLUG,(FOR 3CV)

SN: 800001-UP

3шт.

|$70

KH50107145

PLUG,(FOR 4CV)

SN: 800001-UP

4шт.

|$71

KH50107145

PLUG,(FOR 5CV)

SN: 800001-UP

5шт.

18

KH03560-0549

PLUG

SN: 800001-UP

2шт.

19

KHOORBP16

O-RING,(FOR 2CV)

SN: 800001-UP

2шт.

|$74

KHOORBP16

O-RING,(FOR 3CV)

SN: 800001-UP

3шт.

|$75

KHOORBP16

O-RING,(FOR 4CV)

SN: 800001-UP

4шт.

|$76

KHOORBP16

O-RING,(FOR 5CV)

SN: 800001-UP

5шт.

20

KHOORBP14

O-RING

SN: 800001-UP

2шт.

21

KHV9709091256

RELEF VALVE ASS'Y

SN: 800001-UP

1шт.

22

KHVZ203340-005

SPRING

SN: 800001-UP

1шт.

23

KHVZ03340-1858

SPRING

SN: 802377-UP

1шт.

|$81

KHVZ203340-122

SPRING

SN: 800001-802376

1шт.

24

KHVZ33420-0300

ROD

SN: 802377-UP

1шт.

|$83

KHVZ233420-020

ROD

SN: 800001-802376

1шт.

25

KHOROH38

PLUG

SN: 800001-UP

4шт.

26

KHOORBP14

O-RING

SN: 800001-UP

4шт.

27

KHVZ03560-0545

PLUG

SN: 800001-UP

1шт.

28

KHOORBP16

O-RING

SN: 800001-UP

1шт.

29

KHVZ37220-0005

HOUSING

SN: 800001-UP

1шт.

30

KHVZ37220-0006

PLATE

SN: 800001-UP

2шт.

31

KHVZ37220-0009

HOUSING

SN: 800001-UP

2шт.

32

KHVZ37220-0010

PLATE

SN: 800001-UP

2шт.
