Запчасти Komatsu FB15 ДЛЯ 4-Х СЕКЦИОНН. УПРАВЛЯЮЩ. КЛАПАН FV МАЧТА (ДЛЯ .M - .7M МАЧТА) РАБОЧЕЕ ОБОРУДОВАНИЕ

1

45A-5MA-1170

CLIP

SN: 807001-UP

2шт.

2

01024-80830

BOLT

SN: 807001-UP

4шт.

3

45A-1MA-5110SA

BRACKET

SN: 807001-UP

2шт.

|$13

45A-1MA-5110WK

BRACKET,(COLD)

SN: 807001-UP

2шт.

4

01024-80820

BOLT

SN: 807001-UP

4шт.

5

45B-5MA-2040SA

CLIP

SN: 807001-UP

2шт.

|$16

45B-5MA-2040WK

CLIP,(COLD)

SN: 807001-UP

2шт.

6

01024-80830

BOLT

SN: 807001-UP

4шт.

7

304-868-2240

CLAMP

SN: 807001-UP

2шт.

8

304-868-2250

RUBBER

SN: 807001-UP

4шт.

9

01024-80840

BOLT

SN: 807001-UP

4шт.

10

45C-2MA-1200

PULLEY

SN: 807001-UP

2шт.

11

45A-1MH-5110SA

BRACKET,(L.H.)

SN: 807001-UP

1шт.

|$25

45A-1MH-5110WK

BRACKET,(L.H.)(COLD)

SN: 807001-UP

1шт.

12

45A-1MA-3110SA

BRACKET

SN: 807001-UP

1шт.

|$27

45A-1MA-3110WK

BRACKET,(COLD)

SN: 807001-UP

1шт.

13

01580-11210

NUT

SN: 807001-UP

2шт.

14

01643-31232

WASHER

SN: 807001-UP

2шт.

15

01024-81030

BOLT

SN: 807001-UP

4шт.

16

45B-5MA-1190SA

PIPE

SN: 807001-UP

4шт.

|$32

45B-5MA-1190WK

PIPE,(COLD)

SN: 807001-UP

4шт.

17

01010-81090

BOLT

SN: 807001-UP

4шт.

18

01580-11008

NUT

SN: 807001-UP

4шт.

19

07123-00324

HOSE,(FOR 3.0M MAST)

SN: 807001-UP

4шт.

|$44

07123-00325

HOSE,(FOR 3.3M MAST)

SN: 807001-UP

4шт.

|$45

07123-00327

HOSE,(FOR 3.5M MAST)

SN: 807001-UP

4шт.

|$46

07123-00328

HOSE,(FOR 3.7M MAST)

SN: 807001-UP

4шт.

20

37B-ZAN-7010YK

PIPE,(FOR 3.0M MAST)

SN: 807001-UP

2шт.

|$48

37B-ZAN-7010WK

PIPE,(FOR 3.0M MAST) (COLD)

SN: 807001-UP

2шт.

|$49

37B-ZAN-7030YK

PIPE,(FOR 3.3M MAST)

SN: 807001-UP

2шт.

|$50

37B-ZAN-7030WK

PIPE,(FOR 3.3M MAST) (COLD)

SN: 807001-UP

2шт.

|$51

37B-ZAN-7030YK

PIPE,(FOR 3.5M MAST)

SN: 807001-UP

2шт.

|$52

37B-ZAN-7030WK

PIPE,(FOR 3.5M MAST) (COLD)

SN: 807001-UP

2шт.

|$53

37B-ZAN-7040YK

PIPE,(FOR 3.7M MAST)

SN: 807001-UP

2шт.

|$54

37B-ZAN-7040WK

PIPE,(FOR 3.7M MAST) (COLD)

SN: 807001-UP

2шт.

21

37B-ZAS-7010YK

PIPE,(FOR 3.0M MAST)

SN: 807001-UP

2шт.

|$56

37B-ZAS-7010WK

PIPE,(FOR 3.0M MAST) (COLD)

SN: 807001-UP

2шт.

|$57

37B-ZAS-7030YK

PIPE,(FOR 3.3M MAST)

SN: 807001-UP

2шт.

|$58

37B-ZAS-7030WK

PIPE,(FOR 3.3M MAST) (COLD)

SN: 807001-UP

2шт.

|$59

37B-ZAS-7030YK

PIPE,(FOR 3.5M MAST)

SN: 807001-UP

2шт.

|$60

37B-ZAS-7030WK

PIPE,(FOR 3.5M MAST) (COLD)

SN: 807001-UP

2шт.

|$61

37B-ZAS-7040YK

PIPE,(FOR 3.7M MAST)

SN: 807001-UP

2шт.

|$62

37B-ZAS-7040WK

PIPE,(FOR 3.7M MAST) (COLD)

SN: 807001-UP

2шт.

22

45A-1MA-5120SA

BRACKET,(R.H.)

SN: 807001-UP

1шт.

|$64

45A-1MA-5120WK

BRACKET,(R.H.)(COLD)

SN: 807001-UP

1шт.

23

45A-1MA-5130SA

BRACKET,(L.H.)

SN: 807001-UP

1шт.

|$66

45A-1MA-5130WK

BRACKET,(L.H.)(COLD)

SN: 807001-UP

1шт.

24

01024-80820

BOLT

SN: 807001-UP

4шт.
