Запчасти Komatsu FB15 ДЛЯ 3-Х СЕКЦИОНН. КОНТРОЛЬН. КЛАПАН FFV МАЧТА (РУКАВНЫЙ БАРАБАН ТИП) (ДЛЯ .M - .M МАЧТА) РАБОЧЕЕ ОБОРУДОВАНИЕ

1

3EA-66-26220SA

ELBOW,(FOR 3.0M AND 3.3M MAST)

SN: 807001-UP

2шт.

|$21

3EA-66-26220WK

ELBOW,(FOR 3.0M AND 3.3M MAST)(COLD)

SN: 807001-UP

2шт.

|$22

37B-ZKX-1050SA

PIPE,(FOR 3.5M TO 4.0M MAST)

SN: 807001-UP

2шт.

|$23

37B-ZKX-1050WK

PIPE,(FOR 3.5M TO 4.0M MAST) (COLD)

SN: 807001-UP

2шт.

2

07123-00324

HOSE,(FOR 3.0M MAST)

SN: 807001-UP

2шт.

|$25

07123-00327

HOSE,(FOR 3.3M MAST)

SN: 807001-UP

2шт.

|$26

07123-00324

HOSE,(FOR 3.5M MAST)

SN: 807001-UP

2шт.

|$27

07123-00327

HOSE,(FOR 3.7M AND 4.0M MAST)

SN: 807001-UP

2шт.

3

07123-00305

HOSE,(FOR 3.0M AND 3.3M MAST)

SN: 807001-UP

2шт.

|$29

07123-00310

HOSE,(FOR 3.5M MAST)

SN: 807001-UP

2шт.

|$30

07123-00311

HOSE,(FOR 3.7M MAST)

SN: 807001-UP

2шт.

|$31

07123-00313

HOSE,(FOR 4.0M MAST)

SN: 807001-UP

2шт.

4

37B-1AE-6010

BAND,(FOR 3.0M AND 3.3M MAST)

SN: 807001-UP

2шт.

|$33

37B-1AE-6010

BAND,(FOR 3.5M TO 4.0M MAST)

SN: 807001-UP

4шт.

5

37B-1AE-6030

BAND,(FOR 3.5M TO 4.0M MAST)

SN: 807001-UP

4шт.

6

01024-81280

BOLT

SN: 807001-UP

2шт.

7

45A-1MD-5010YK

BRACKET

SN: 807001-UP

1шт.

|$37

45A-1MD-5010WK

BRACKET,(COLD)

SN: 807001-UP

1шт.

8

01024-81235

BOLT

SN: 807001-UP

2шт.

9

3EA-68-21110SA

PIPE

SN: 807001-UP

1шт.

|$40

3EA-68-21110WK

PIPE,(COLD)

SN: 807001-UP

1шт.

10

3EA-68-21120SA

PIPE

SN: 807001-UP

1шт.

|$42

3EA-68-21120WK

PIPE,(COLD)

SN: 807001-UP

1шт.

11

45A-1MF-5060YK

BRACKET

SN: 807001-UP

1шт.

|$44

45A-1MF-5060WK

BRACKET,(COLD)

SN: 807001-UP

1шт.

12

01024-80820

BOLT

SN: 807001-UP

2шт.

13

304-833-2250

CLAMP

SN: 807001-UP

2шт.

14

01024-80830

BOLT

SN: 807001-UP

2шт.

15

37B-ZE7-1020

HOSE REEL ASS'Y,(FOR 3.0M AND 3.3M MAST)

SN: 807001-UP

1шт.

|$49

37B-ZE7-1010

HOSE REEL ASS'Y,(FOR 3.5M AND 3.7M MAST)

SN: 807001-UP

1шт.

|$50

37B-ZE7-1030

HOSE REEL ASS'Y,(FOR 4.0M MAST)

SN: 807001-UP

1шт.

16

46B-1FS-5300

JUNCTION BLOCK

SN: 807001-UP

1шт.
