Запчасти Komatsu FB15 ГИДРОЦИЛИНДР ПОДЪЕМА (ДЛЯ FREE VIEW ПОЛН. FREE МАЧТА) (ЗАДН. ПРАВ.) (EXCEPT FB/8RJW) (/) МАЧТА
№
Артикул
Название
Примечание
Количество
|$25
37A-MDW-1301YD
LIFT CYLINDER ASS'Y,(FOR 3.0M MAST)
SN: 80001-UP
1шт.
|$26
37A-MDW-1331YD
LIFT CYLINDER ASS'Y,(FOR 3.3M MAST)
SN: 80001-UP
1шт.
|$27
37A-MDW-1351YD
LIFT CYLINDER ASS'Y,(FOR 3.5M MAST)
SN: 80001-UP
1шт.
|$28
37A-MDW-1371YD
LIFT CYLINDER ASS'Y,(FOR 3.7M MAST)
SN: 80001-UP
1шт.
|$29
37A-MDW-1011YD
LIFT CYLINDER ASS'Y,(FOR 4.0M MAST)
SN: 80001-UP
1шт.
|$30
37A-MDW-1301WD
LIFT CYLINDER ASS'Y,(FOR 3.0M MAST) (COLD)
SN: 80001-UP
1шт.
|$31
37A-MDW-1331WD
LIFT CYLINDER ASS'Y,(FOR 3.3M MAST) (COLD)
SN: 80001-UP
1шт.
|$32
37A-MDW-1351WD
LIFT CYLINDER ASS'Y,(FOR 3.5M MAST) (COLD)
SN: 80001-UP
1шт.
|$33
37A-MDW-1371WD
LIFT CYLINDER ASS'Y,(FOR 3.7M MAST) (COLD)
SN: 80001-UP
1шт.
|$34
37A-MDW-1011WD
LIFT CYLINDER ASS'Y,(FOR 4.0M MAST) (COLD)
SN: 80001-UP
1шт.
1
37A-MDY-1301
CYLINDER,(FOR 3.0M MAST)
SN: 80001-UP
1шт.
|$36
37A-MDY-1331
CYLINDER,(FOR 3.3M MAST)
SN: 80001-UP
1шт.
|$37
37A-MDY-1351
CYLINDER,(FOR 3.5M MAST)
SN: 80001-UP
1шт.
|$38
37A-MDY-1371
CYLINDER,(FOR 3.7M MAST)
SN: 80001-UP
1шт.
|$39
37A-MDY-1011
CYLINDER,(FOR 4.0M MAST)
SN: 80001-UP
1шт.
2
37A-MAX-1300
ROD,(FOR 3.0M MAST)
SN: 80001-UP
1шт.
|$41
37A-MAX-1330
ROD,(FOR 3.3M MAST)
SN: 80001-UP
1шт.
|$42
37A-MAX-1350
ROD,(FOR 3.5M MAST)
SN: 80001-UP
1шт.
|$43
37A-MAX-1370
ROD,(FOR 3.7M MAST)
SN: 80001-UP
1шт.
|$44
37A-MAX-1010
ROD,(FOR 4.0M MAST)
SN: 80001-UP
1шт.
3
3EA-M1-16210
PISTON
SN: 80001-UP
1шт.
4
34B-63-24130
SCREW
SN: 80001-UP
1шт.
6
3EA-63-11140
U-RING
SN: 80001-UP
1шт.
7
3EA-63-11150
HOLDER
SN: 80001-UP
1шт.
8
3EA-63-11160
RING
SN: 80001-UP
1шт.
9
3EA-M1-16110
HEAD
SN: 80001-UP
1шт.
10
3EA-M1-16120
BUSHING
SN: 80001-UP
1шт.
11
3EA-N1-16130
PACKING
SN: 80001-UP
1шт.
12
3EA-M1-16150
SPACER
SN: 80001-UP
1шт.
14
34B-63-17680
O-RING
SN: 80001-UP
1шт.
15
540-61-13190
BALL
SN: 80001-UP
1шт.
16
4610-64-1160
SCREW
SN: 80001-UP
1шт.
Выбрано товаров: 34
