Запчасти Komatsu FB18M-3 ВНУТР. МАЧТА РАБОЧЕЕ ОБОРУДОВАНИЕ И СИСТЕМА УПРАВЛЕНИЯ

1

37A-7LD-1301

MAST,INNER (FOR 3.0M MAST)

SN: 10001-UP

1шт.

|$1

37A-7LD-1301WD

MAST,INNER (FOR 3.0M MAST) (COLD)

SN: 10001-UP

1шт.

|$2

37A-7LD-1331

MAST,INNER (FOR 3.3M MAST)

SN: 10001-UP

1шт.

|$3

37A-7LD-1331WD

MAST,INNER (FOR 3.3M MAST) (COLD)

SN: 10001-UP

1шт.

|$4

37A-7LD-1351

MAST,INNER (FOR 3.5M MAST)

SN: 10001-UP

1шт.

|$5

37A-7LD-1351WD

MAST,INNER (FOR 3.5M MAST) (COLD)

SN: 10001-UP

1шт.

|$6

37A-7LD-1371

MAST,INNER (FOR 3.7M MAST)

SN: 10001-UP

1шт.

|$7

37A-7LD-1371WD

MAST,INNER (FOR 3.7M MAST) (COLD)

SN: 10001-UP

1шт.

|$8

37A-7LD-1401

MAST,INNER (FOR 4.0M MAST)

SN: 10001-UP

1шт.

|$9

37A-7LD-1401WD

MAST,INNER (FOR 4.0M MAST) (COLD)

SN: 10001-UP

1шт.

|$10

37A-7LD-1431

MAST,INNER (FOR 4.3M MAST)

SN: 10001-UP

1шт.

|$11

37A-7LD-1431WD

MAST,INNER (FOR 4.3M MAST) (COLD)

SN: 10001-UP

1шт.

|$12

37A-7LD-1451

MAST,INNER (FOR 4.5M MAST)

SN: 10001-UP

1шт.

|$13

37A-7LD-1451WD

MAST,INNER (FOR 4.5M MAST) (COLD)

SN: 10001-UP

1шт.

|$14

37A-7LD-1501

MAST,INNER (FOR 5.0M MAST)

SN: 10001-UP

1шт.

|$15

37A-7LD-1501WD

MAST,INNER (FOR 5.0M MAST) (COLD)

SN: 10001-UP

1шт.

2

3BA-T9-12610

ROLLER,(S)

SN: 10001-UP

2шт.

|$17

3BA-T9-18610

ROLLER,(S) (COLD SPEC.)

SN: 10001-UP

2шт.

|$18

3BA-T9-12620

ROLLER,(M)

SN: 10001-UP

2шт.

|$19

3BA-T9-18620

ROLLER,(M) (COLD SPEC.)

SN: 10001-UP

2шт.

|$20

34A-72-11880

ROLLER,(L)

SN: 10001-UP

2шт.

|$21

34A-72-17660

ROLLER,(L) (COLD SPEC.)

SN: 10001-UP

2шт.

3

34A-72-00010

SHIM ASS'Y

SN: 10001-UP

2шт.

4

04064-03515

RING,SNAP

SN: 10001-UP

2шт.

5

34A-72-11150

WHEEL

SN: 10001-UP

2шт.

|$25

34A-72-17690

WHEEL,(COLD SPEC.)

SN: 10001-UP

2шт.

6

37A-749-3030

SHIM, 1.0MM

SN: 10001-UP

2шт.

7

04064-03015

RING,SNAP

SN: 10001-UP

2шт.

8

01010-51235

BOLT

SN: 10001-UP

2шт.

9

01602-21236

WASHER,SPRING

SN: 10001-UP

2шт.

10

3EA-71-00020

SHIM ASS'Y

SN: 10001-UP

2шт.

11

37A-737-1301

CHAIN,(FOR 3.0M MAST)

SN: 10001-UP

2шт.

|$32

37A-737-1331

CHAIN,(FOR 3.3M MAST)

SN: 10001-UP

2шт.

|$33

37A-737-1351

CHAIN,(FOR 3.5M MAST)

SN: 10001-UP

2шт.

|$34

37A-737-1371

CHAIN,(FOR 3.7M MAST)

SN: 10001-UP

2шт.

|$35

37A-737-1401

CHAIN,(FOR 4.0M MAST)

SN: 10001-UP

2шт.

|$36

37A-737-1431

CHAIN,(FOR 4.3M MAST)

SN: 10001-UP

2шт.

|$37

37A-737-1451

CHAIN,(FOR 4.5M MAST)

SN: 10001-UP

2шт.

|$38

37A-737-1501

CHAIN,(FOR 5.0M MAST)

SN: 10001-UP

2шт.

12

3EA-71-12740

BOLT

SN: 10001-UP

2шт.

13

01582-11411

NUT

SN: 10001-UP

6шт.

14

34A-71-11611

BOLT

SN: 10001-UP

2шт.

15

3EP-71-11970

NUT

SN: 10001-UP

6шт.
