Запчасти Komatsu FB20 ГИДРОЦИЛИНДР ПОДЪЕМА (ДЛЯ .M - .M МАЧТА) МАЧТА

Схема запчастей Komatsu FB20 - ГИДРОЦИЛИНДР ПОДЪЕМА (ДЛЯ .M - .M МАЧТА) МАЧТА
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15

Артикул

Название

Примечание

Количество

|$10

37B-7QT-3300YD

LIFT CYLINDER ASS'Y,(FOR 3.0M MAST)

SN: 810001-UP

1шт.

|$11

37B-7QT-3330YD

LIFT CYLINDER ASS'Y,(FOR 3.3M MAST)

SN: 810001-UP

2шт.

|$12

37B-7QT-3350YD

LIFT CYLINDER ASS'Y,(FOR 3.5M MAST)

SN: 810001-UP

2шт.

|$13

37B-7QT-3370YD

LIFT CYLINDER ASS'Y,(FOR 3.7M MAST)

SN: 810001-UP

2шт.

|$14

37B-7QT-3400YD

LIFT CYLINDER ASS'Y,(FOR 4.0M MAST)

SN: 810001-UP

2шт.

|$15

37B-7QT-3430YD

LIFT CYLINDER ASS'Y,(FOR 4.3M MAST)

SN: 810001-UP

2шт.

|$16

37B-7QT-3450YD

LIFT CYLINDER ASS'Y,(FOR 4.5M MAST)

SN: 810001-UP

2шт.

|$17

37B-7QT-3470YD

LIFT CYLINDER ASS'Y,(FOR 4.7M MAST)

SN: 810001-UP

2шт.

|$18

37B-7QT-3500YD

LIFT CYLINDER ASS'Y,(FOR 5.0M MAST)

SN: 810001-UP

2шт.

|$19

37B-7RT-3550YD

LIFT CYLINDER ASS'Y,(FOR 5.5M MAST)

SN: 810001-UP

2шт.

1

KBB6527-16001

CYLINDER TUBE ASS'Y,(FOR 3.0M MAST)

SN: 810001-UP

1шт.

|$21

KBB6527-16301

CYLINDER TUBE ASS'Y,(FOR 3.3M MAST)

SN: 810001-UP

1шт.

|$22

KBB6527-16501

CYLINDER TUBE ASS'Y,(FOR 3.5M MAST)

SN: 810001-UP

1шт.

|$23

KBB6527-16701

CYLINDER TUBE ASS'Y,(FOR 3.7M MAST)

SN: 810001-UP

1шт.

|$24

KBB6527-17001

CYLINDER TUBE ASS'Y,(FOR 4.0M MAST)

SN: 810001-UP

1шт.

|$25

KBB6527-17301

CYLINDER TUBE ASS'Y,(FOR 4.3M MAST)

SN: 810001-UP

1шт.

|$26

KBB6527-17501

CYLINDER TUBE ASS'Y,(FOR 4.5M MAST)

SN: 810001-UP

1шт.

|$27

KBB6527-17701

CYLINDER TUBE ASS'Y,(FOR 4.7M MAST)

SN: 810001-UP

1шт.

|$28

KBB6527-18001

CYLINDER TUBE ASS'Y,(FOR 5.0M MAST)

SN: 810001-UP

1шт.

|$29

KBB6527-26501

CYLINDER TUBE ASS'Y,(FOR 5.5M MAST)

SN: 810001-UP

1шт.

2

KBB6527-16002

PISTON ROD ASS'Y,(FOR 3.0M MAST)

SN: 810001-UP

1шт.

|$31

KBB6527-16302

PISTON ROD ASS'Y,(FOR 3.3M MAST)

SN: 810001-UP

1шт.

|$32

KBB6527-16502

PISTON ROD ASS'Y,(FOR 3.5M MAST)

SN: 810001-UP

1шт.

|$33

KBB6527-16702

PISTON ROD ASS'Y,(FOR 3.7M MAST)

SN: 810001-UP

1шт.

|$34

KBB6527-17002

PISTON ROD ASS'Y,(FOR 4.0M MAST)

SN: 810001-UP

1шт.

|$35

KBB6527-17302

PISTON ROD ASS'Y,(FOR 4.3M MAST)

SN: 810001-UP

1шт.

|$36

KBB6527-17502

PISTON ROD ASS'Y,(FOR 4.5M MAST)

SN: 810001-UP

1шт.

|$37

KBB6527-17702

PISTON ROD ASS'Y,(FOR 4.7M MAST)

SN: 810001-UP

1шт.

|$38

KBB6527-18002

PISTON ROD ASS'Y,(FOR 5.0M MAST)

SN: 810001-UP

1шт.

|$39

KBB6527-26502

PISTON ROD ASS'Y,(FOR 5.5M MAST)

SN: 810001-UP

1шт.

3

KB30121-50102

HEAD,(FOR 3.0M TO 5.0M MAST)

SN: 810001-UP

1шт.

|$41

KB30121-55043

HEAD,(FOR 5.5M MAST)

SN: 810001-UP

1шт.

4

KB30131-40017

BUSHING,(FOR 3.0M TO 5.0M MAST)

SN: 810001-UP

1шт.

|$43

KB30131-45017

BUSHING,(FOR 5.5M MAST)

SN: 810001-UP

1шт.

5

KB30961-04012

U-RING,(FOR 3.0M TO 5.0M MAST) (KIT A)

SN: 810001-UP

1шт.

|$45

KB30961-04512

U-RING,(FOR 5.5M MAST) (KIT B)

SN: 810001-UP

1шт.

6

KB30191-40025

RING,WIPER (FOR 3.0M TO 5.0M MAST) (KIT A)

SN: 810001-UP

1шт.

|$47

KB30191-45025

RING,WIPER (FOR 5.5M MAST) (KIT B)

SN: 810001-UP

1шт.

7

KB30161-91774

O-RING,(FOR 3.0M TO 5.0M MAST) (KIT A)

SN: 810001-UP

1шт.

|$49

KB30161-91775

O-RING,(FOR 5.5M MAST) (KIT B)

SN: 810001-UP

1шт.

8

KB30161-50046

U-RING,(FOR 3.0M TO 5.0M MAST) (KIT A)

SN: 810001-UP

1шт.

|$51

KB30161-55046

U-RING,(FOR 5.5M MAST) (KIT B)

SN: 810001-UP

1шт.

9

KB30461-50039

RING,BACK UP(FOR 3.0M TO 5.0M MAST) (KIT A)

SN: 810001-UP

1шт.

|$53

KB30461-55039

RING,BACK UP(FOR 5.5M MAST) (KIT B)

SN: 810001-UP

1шт.

10

KB30131-50018

BUSHING,(FOR 3.0M TO 5.0M MAST)

SN: 810001-UP

1шт.

|$55

KB30131-55018

BUSHING,(FOR 5.5M MAST)

SN: 810001-UP

1шт.

11

KB30551-91003

BEARING,(FOR 3.0M TO 5.0M MAST)

SN: 810001-UP

1шт.

|$57

KB30551-91001

RING,(FOR 5.5M MAST)

SN: 810001-UP

1шт.

12

KB30141-91049

RING,(FOR 3.0M TO 5.0M MAST)

SN: 810001-UP

1шт.

|$59

KB30141-91048

SNAP RING,(FOR 5.5M MAST)

SN: 810001-UP

1шт.

13

34A-63-17170

SPACER,(FOR 4.0M TO 4.5M MAST)

SN: 810001-UP

1шт.

|$61

34A-63-17190

SPACER,(FOR 4.7M TO 5.0M MAST)

SN: 810001-UP

1шт.

|$62

34B-63-16390

SPACER,(FOR 5.5M MAST)

SN: 810001-UP

1шт.

14

KB95123-03500

O-RING,(FOR 3.0M TO 5.0M MAST)

SN: 810001-UP

1шт.

|$64

KB95123-04000

O-RING,(FOR 5.5M MAST)

SN: 810001-UP

1шт.

15

KB97124-01111

PLUG,(FOR 5.5M MAST)

SN: 810001-UP

1шт.

|$$57

SERVICE KIT

-1шт.

KIT A

KB3050A-00093

SEAL KIT,(FOR 3.0M TO 5.0M MAST)

SN: 810001-UP

2шт.

KIT B

KB3055A-00058

SEAL KIT,(FOR 5.5M MAST)

SN: 810001-UP

2шт.

Выбрано товаров: 59
