Запчасти Komatsu FG20H-25H-14 MIDDLE МАЧТА (VT .T-.T) МАЧТА И СТРЕЛА

1

37B-TAC-3371

MAST,MIDDLE, (FOR 3.7M MAST)

SN: 550001-UP

1шт.

|$41

37B-TAC-3401

MAST,MIDDLE, (FOR 4.0M MAST)

SN: 550001-UP

1шт.

|$42

37B-TAC-3431

MAST,MIDDLE, (FOR 4.3M MAST)

SN: 550001-UP

1шт.

|$43

37B-TAC-3451

MAST,MIDDLE, (FOR 4.5M MAST)

SN: 550001-UP

1шт.

|$44

37B-TAC-3471

MAST,MIDDLE, (FOR 4.7M MAST)

SN: 550001-UP

1шт.

|$45

37B-TAC-3501

MAST,MIDDLE, (FOR 5.0M MAST)

SN: 550001-UP

1шт.

|$46

37B-TAC-3551

MAST,MIDDLE, (FOR 5.5M MAST)

SN: 550001-UP

1шт.

|$47

37B-TAC-3601

MAST,MIDDLE, (FOR 6.0M MAST)

SN: 550001-UP

1шт.

|$48

37B-TAC-3651

MAST,MIDDLE, (FOR 6.5M MAST)

SN: 550001-UP

1шт.

|$49

37B-TAC-3701

MAST,MIDDLE, (FOR 7.0M MAST)

SN: 550001-UP

1шт.

2

37B-9AA-1511

ROLLER,(S)

SN: 550001-UP

2шт.

|$51

37B-9AA-1521

ROLLER,(M)

SN: 550001-UP

2шт.

|$52

37B-9AA-1531

ROLLER,(L)

SN: 550001-UP

2шт.

3

3EB-71-00060

SHIM ASS'Y

SN: 550001-UP

2шт.

|$54

0

SHIM, 0.2MM

SN: 550001-UP

-2шт.

|$55

0

SHIM, 0.5MM

SN: 550001-UP

-2шт.

|$56

0

SHIM, 1.0MM

SN: 550001-UP

-2шт.

|$57

0

SHIM, 2.3MM

SN: 550001-UP

-2шт.

4

04064-04018

RING,SNAP

SN: 550001-UP

2шт.

5

37B-9AA-1111

ROLLER,(S)

SN: 550001-UP

2шт.

|$60

37B-9AA-1121

ROLLER,(M)

SN: 550001-UP

2шт.

|$61

37B-9AA-1131

ROLLER,(L)

SN: 550001-UP

2шт.

6

3EB-71-00050

SHIM ASS'Y

SN: 550001-UP

2шт.

|$63

0

SHIM, 0.2MM

SN: 550001-UP

-2шт.

|$64

0

SHIM, 0.5MM

SN: 550001-UP

-2шт.

|$65

0

SHIM, 1.0MM

SN: 550001-UP

-2шт.

|$66

0

SHIM, 2.3MM

SN: 550001-UP

-2шт.

7

3EB-71-31640

STRIP

SN: 550001-UP

2шт.

8

3EB-71-00090

SHIM ASS'Y

SN: 550001-UP

2шт.

|$69

0

SHIM, 0.5MM

SN: 550001-UP

-2шт.

|$70

0

SHIM, 1.0MM

SN: 550001-UP

-2шт.

9

34B-76-52871

WHEEL ASS'Y

SN: 550001-UP

2шт.

10

37B-9AC-2020

SHIM, 0.5MM

SN: 550001-UP

4шт.

|$73

37B-9AC-2030

SHIM, 1.0MM

SN: 550001-UP

10шт.

11

04064-04018

RING,SNAP

SN: 550001-UP

2шт.

12

3EB-71-00070

SHIM ASS'Y

SN: 550001-UP

2шт.

|$76

0

SHIM, 0.5MM

SN: 550001-UP

-2шт.

|$77

0

SHIM, 1.0MM

SN: 550001-UP

-2шт.

|$78

0

SHIM, 2.3MM

SN: 550001-UP

-2шт.

13

01016-81030

BOLT

SN: 550001-UP

2шт.

14

01580-11008

NUT

SN: 550001-UP

2шт.

|$81

37B-9CA-2400

CHAIN ASS'Y,(FOR 3.7M MAST)

SN: 550001-UP

2шт.

|$82

37B-9CA-2430

CHAIN ASS'Y,(FOR 4.0M MAST)

SN: 550001-UP

2шт.

|$83

37B-9CA-2450

CHAIN ASS'Y,(FOR 4.3M MAST)

SN: 550001-UP

2шт.

|$84

37B-9CA-2470

CHAIN ASS'Y,(FOR 4.5M MAST)

SN: 550001-UP

2шт.

|$85

37B-9CA-2490

CHAIN ASS'Y,(FOR 4.7M MAST)

SN: 550001-UP

2шт.

|$86

37B-9CA-2520

CHAIN ASS'Y,(FOR 5.0M MAST)

SN: 550001-UP

2шт.

|$87

37B-9CA-2570

CHAIN ASS'Y,(FOR 5.5M MAST)

SN: 550001-UP

2шт.

|$88

37B-9CA-2620

CHAIN ASS'Y,(FOR 6.0M MAST)

SN: 550001-UP

2шт.

|$89

37B-9CA-2670

CHAIN ASS'Y,(FOR 6.5M MAST)

SN: 550001-UP

2шт.

|$90

37B-9CA-2720

CHAIN ASS'Y,(FOR 7.0M MAST)

SN: 550001-UP

2шт.

15

37B-737-1240

CHAIN,(FOR 3.7M MAST)

SN: 550001-UP

1шт.

|$92

37B-737-1260

CHAIN,(FOR 4.0M MAST)

SN: 550001-UP

1шт.

|$93

37B-737-1280

CHAIN,(FOR 4.3M MAST)

SN: 550001-UP

1шт.

|$94

37B-737-1290

CHAIN,(FOR 4.5M MAST)

SN: 550001-UP

1шт.

|$95

37B-737-1310

CHAIN,(FOR 4.7M MAST)

SN: 550001-UP

1шт.

|$96

37B-737-1330

CHAIN,(FOR 5.0M MAST)

SN: 550001-UP

1шт.

|$97

37B-737-1370

CHAIN,(FOR 5.5M MAST)

SN: 550001-UP

1шт.

|$98

37B-737-1400

CHAIN,(FOR 6.0M MAST)

SN: 550001-UP

1шт.

|$99

37B-787-1190

CHAIN,(FOR 6.5M MAST)

SN: 550001-UP

1шт.

|$100

37B-737-1460

CHAIN,(FOR 7.0M MAST)

SN: 550001-UP

1шт.

16

3EB-71-21551

STOPPER

SN: 550001-UP

2шт.

17

01582-11613

NUT

SN: 550001-UP

8шт.

18

3EB-T2-31710

BRACKET

SN: 550001-UP

1шт.

19

01010-81230

BOLT

SN: 550001-UP

2шт.

20

01602-21236

WASHER,SPRING

SN: 550001-UP

2шт.

21

3BB-T1-11750

BRACKET

SN: 550001-UP

1шт.

22

3BB-T2-11760

PULLEY

SN: 550001-UP

1шт.

23

06002-06004

BEARING

SN: 550001-UP

2шт.

24

3EB-T2-11770

WASHER

SN: 550001-UP

1шт.

25

04064-02012

RING,SNAP

SN: 550001-UP

1шт.

26

01010-81235

BOLT

SN: 550001-UP

2шт.

27

01602-21236

WASHER,SPRING

SN: 550001-UP

2шт.

28

01643-31232

WASHER

SN: 550001-UP

2шт.
